110L Rubber Banbury Mixer with 185KW Driving Motor and Hard Chrome Plated Rotors for High Efficiency Mixing
Price:
9999.00-12999.00USD per Set
MOQ:
1 Set
Delivery Time:
50 days
Brand:
SFC
Product Description
Factory Price 110L Rubber Banbury Mixer Machine
Rubber Kneader Machine / Rubber Banbury Mixer
Product Overview
- High Efficiency: Rubber or plastic materials are plasticized or mixed with high productivity in a closed, pressurized, and temperature-controlled environment.
- Energy Saving: Capacity is 6-8 times greater compared to open mills under the same power conditions.
- Eco-Friendly: Special dust sealing unit provides reliable environmental protection.
- Durable Construction: Banbury rotor made from 42CrMo material with hard chrome plating for exceptional wear resistance. Speed reducer and gearbox are equally durable.
- Excellent Temperature Control: All parts contacting materials feature jacket structure for optimal cooling/heating, adaptable to various rubber or plastic mixing requirements.
- Superior Mixing Quality: Optimized parameters including helical angle of rotor wings and wing overlap length ensure homogeneous material distribution.
Technical Specifications
| Model | X(S)N-20x32 | X(S)N-25x32 | X(S)N-35x30 | X(S)N-55x30 | X(S)N-75x30 | X(S)N-110x30 | X(S)N-150x30 | X(S)N-200x30 |
|---|---|---|---|---|---|---|---|---|
| Total Volume of Mixing Chamber (L) | 45 | 55 | 75 | 125 | 170 | 250 | 325 | 440 |
| Working Volume of Mixing Chamber (L) | 20 | 25 | 35 | 55 | 75 | 110 | 150 | 200 |
| Driving Motor Power (KW) | 37 | 37 | 55 | 75 | 110 | 185 | 220 | 280 |
| Tilting Motor Power (KW) | 1.5 | 1.5 | 2.2 | 2.2 | 4 | 5.5 | 11 | 11 |
| Rotational Speed of The Rotor (front/rear) (r/min) | 32/27 | 32/27 | 30/24.5 | 30/24.5 | 30/24.5 | 30/24.5 | 30/24.5 | 30/24.5 |
| Pressure of Compressed Air (m³/min) | ≥0.7 | ≥0.7 | ≥0.9 | ≥1.0 | ≥1.0 | ≥1.5 | ≥2.0 | ≥4.0 |
| Pressure of Cooling Water (mixing rubber) (MPa) | 0.2~0.4 | 0.2~0.4 | 0.3~0.4 | 0.3~0.4 | 0.3~0.4 | 0.3~0.4 | 0.3~0.4 | 0.3~0.4 |
| Pressure of Heating Steam (plastic mixing) (MPa) | 0.5~0.8 | 0.5~0.8 | 0.5~0.8 | 0.5~0.8 | 0.5~0.8 | 0.5~0.8 | 0.5~0.8 | 0.5~0.8 |
| Dimensions (LxWxH) (mm) | 2675x1650x2560 | 2675x1650x2560 | 3200x1900x2950 | 3230x1927x2958 | 3325x2615x3150 | 4075x2712x3580 | 4250x2750x4106 | 4250x3400x4215 |
| Gross Weight (T) | ~4 | ~4.5 | ~6.3 | ~7.1 | ~9.5 | ~14.9 | ~19.5 | ~22.5 |
Company Profile
Qingdao Shun Cheong Rubber Machinery Manufacturing Co., Ltd. is a Chinese manufacturer established in 2007 with over 10 years of experience in producing various rubber machinery. The company holds ISO 9001:2008, SGS, and CE certifications.
Our factory specializes in rubber kneaders/rubber mixing mills, various plate vulcanizing presses, 2-roll/3-roll/4-roll rubber calenders, rubber batch off coolers, waste tire recycling lines, reclaimed rubber production lines, conveyor belt production lines, and rubber seals extruding & vulcanizing lines.
Global Markets: Our machinery has been exported to America, Mexico, India, Vietnam, South Africa, Singapore, Malaysia, Indonesia, Australia, Sri Lanka, and many other countries and regions.
Quality Commitment
- Every component passes strict quality inspection before storage
- All products undergo overload trial running before shipment
- Plate Vulcanizing Press tested for 24 hours under 1.25 times rated working pressure
- Rubber Mixing Mill tested mixing rubber for 20 minutes under 1.1 times rated capacity
- Comprehensive free technical support for all products
- 3-year warranty for main parts, 1-year warranty for wearing parts
- Immediate technical support via internet or telephone for quality issues
- On-site engineer repair services when needed
- Customer visits to production sites for consultation available
Our Services
- Custom machine design with engineering drawings for customer confirmation
- Production progress photos provided throughout manufacturing process
- Complete documentation including packing list, commercial invoice, and bill of lading
- Free technical documentation: foundation DWG, installation drawings, user guides, maintenance manuals, and part drawings
Frequently Asked Questions
What does your factory do regarding quality control?
We implement comprehensive quality control throughout the entire production process. Every machine is fully assembled and carefully tested before shipment to ensure optimal performance.
What's the machine quality guarantee?
We provide a one-year quality guarantee. Our machines incorporate world-famous brand components to maintain perfect working condition and ensure long-term reliability.
Are you able to give installation and commissioning overseas? How long will it take?
Yes, we provide overseas installation and technical support services. Installation costs are covered by the customer. Small machines typically require 2-3 days, while large production lines may take approximately 30 days.
How can I trust you to deliver the right machine as I ordered?
We guarantee delivery of high-quality machines exactly as discussed and confirmed in your order. Our company culture is built on innovation, quality, integrity, and efficiency. We have established successful partnerships with world-renowned rubber production manufacturers and welcome customer visits to our facilities.
How can we visit your facility?
We are located in Qingdao City, Shandong Province, China. The nearest airport is Qingdao Jiaodong International Airport. We provide airport pickup services for visiting customers.
