SFC XQL-125 CE Compact Rubber Bale Cutter with 5.5KW Power and 125KN Pressure for High Efficiency Rubber Block Cutting
Single Blade Rubber Bale Cutter, Cutter Machine, Rubber Bale Cutting Machine, Rubber Bale Cutter, Rubber Cutter XQL-80
The Rubber Bale Cutter is a crucial machine employed in rubber factories for processing raw materials. Its primary purpose is to cut natural rubber or synthetic rubber into small blocks that are easy to mix and meet specific requirements.
The XQL-80 Single Knife Hydraulic Rubber Cutter features a compact structure, user-friendly operation, minimal wearing parts, and easy maintenance. It serves as an essential machine for raw material processing.
The XQL-80 consists of:
- Motor and vane pump
- Magnetic exchange valve and overflow valve
- Slave RAM and oil pressure gauge pipe
- Hydro-cylinder support and rubber cutting knife
- Rack and conveying groove
The oil cylinder utilizes a standard hydro-cylinder, while the rack is constructed with high-quality welded steel frame. The rubber cutting knife is made of 9CrSi or T8A, with hardness reaching HRC60 after heat treatment. Underneath the cutting knife, a nylon board protects its edge.
| Type | XQL-80 | XQL-120 | XQL-125 |
|---|---|---|---|
| Width(mm) | 660 | 760 | 760 |
| Stroke(mm) | 680 | 680 | 780 |
| Total Pressure of Oil Cylinder(KN) | 80(about) | 120(about) | 125(about) |
| Time Taken by the Stroke | 14-16 | 13-16 | 14-16 |
| Power(KW) | 5.5 | 5.5 | 5.5 |
| Overall Diameter (LxWxH) (mm) | 1800x600x2450 | 2300x1500x2530 | 2400x1500x2530 |
- High-Efficiency Processing: The QDJ-1200 model can handle 20 to 40 tires every hour, guaranteeing continuous production for large-scale operations. It can process large-sized tires with diameters up to 1200mm, including steel-wire and fiber tires.
- Precision Cutting Technology: Designed for post-bead tires, it achieves clean cuts without damaging internal structures. Can be integrated with other recycling equipment to form complete processing lines.
- Sturdy Construction: Equipped with an 11kW high-torque motor for tough materials. Heavy-duty frame ensures long-term stable performance under continuous operation.
- User-friendly Operation: Fully automatic operation reduces labor costs. Compact structure saves workshop space and simplifies installation/maintenance.
Qingdao Shun Cheong Rubber Machinery Manufacturing Co., Ltd is located in Kangting Road No. 1, Huangdao New District, Qingdao City. We specialize in rubber machinery production and are certified by ISO9001:2015, EU CE, and Switzerland SGS.
Our products serve:
- Tire manufacturing
- Rubber conveyor belt production
- Various rubber products
- Tire refurbished manufacturing
- Waste tire recycling
Main equipment includes:
- Rubber Kneader and Mixing Machine
- Rubber Vulcanizing Press
- Batch Off Cooler and Rubber Calender
- Waste Tire Crusher
- Rubber Extruder and Strainer
Our products are exported to over 50 countries including USA, Germany, Brazil, Russia, and India, earning consistent customer praise.
- All parts undergo strict quality inspection before storage
- Products undergo overload trial running before shipment
- 3-year warranty for main parts, 1-year for wearing parts
- Immediate technical support for any quality issues
- On-site repair services available when needed
- Custom machine design with engineering drawings
- Production progress photos provided
- Complete shipping documentation
- Free technical drawings and manuals
- Overseas engineer support and worker training
We implement strict quality control throughout production. Every machine is fully assembled and tested before shipment.
One-year quality guarantee. We use world-famous brand components to ensure perfect working condition.
Yes, we provide overseas service (customer pays installation cost). Small machines take 2-3 days, production lines about 30 days.
We strictly follow confirmed orders and have cooperated with world-famous rubber manufacturers. Factory visits are welcome.
We're located in Qingdao City, Shandong province, China (Qingdao Jiaodong Airport). We provide airport pickup service.
