PLC Control Compact Body High Automation Fabric Core Conveyor Belt Vulcanizing Press for Rubber Strip Production Line
Type: Conveyor belt have two kinds: fabric core (nylon, canvas etc), steel cord conveyor belt
- Compact body design capable of vulcanizing large-type conveyor belts with high automation level
- Applicable to various conveyor belts including common rubber, nylon, steel cord, and flame-retardant types
- Frame structure host machine with micro fabrication, using superior-quality materials for hot plates and pistons to resist corrosion and wear
- Convenient maintenance, stable working pressure, and easy adjustment capabilities
- PLC-controlled system enabling multi-program automatic control with temperature detection and adjustment
- Enhanced vulcanizing unit performance, reduced labor intensity, and improved production efficiency
- Customizable conveyor belt vulcanizing units available according to customer requirements
- Reference photos
-
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
| Parameter | Unit | XLB-1800x 12000x2 | XLB-1800x 10000x2 | XLB-1600x 10000x2 | XLB-1600x 10000x1 | XLB-1600x 8500x1 | XLB-1400x 10000x1 | XLB-1400x 8000x2 | XLB-1400x 5700x2 | XLB-1100x 5700x2 | XLB-1300x 4000x2 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Hot-plate size | mm | 1800x12000 | 1800x1000 | 1600x10000 | 1600x10000 | 1600x8500 | 1400x10000 | 1400x8000 | 1400x5700 | 1100x5700 | 1300x4000 |
| Total pressure | mn | 74.00 | 72.00 | 56.00 | 64.00 | 47.60 | 49.00 | 34.00 | 25.00 | 17.55 | 14.56 |
| Hot-plate unit pressure | mpa | 3.4 | 4.0 | 3.5 | 4.0 | 3.5 | 3.5 | 3.1 | 3.13 | 2.8 | 2.8 |
| Plunger diameter | mm | 500 | 500 | 450 | 500 | 500 | 450 | 400 | 360 | 500 | 500 |
| Plunger No | 18 | 18 | 18 | 18 | 14 | 18 | 16 | 10 | 5 | 4 | |
| Max plunger stroke | mm | 400 | 300 | 400 | 300 | 300 | 300 | 400 | 400 | 520 | 250 |
| Gripping strength | mn | 1.20 | 1.50 | 1.20 | 1.20 | 0.6 | 0.90 | 1.00 | 0.72 | 0.50 | 0.5 |
| Tension force | mn | 1.101.2 | 1.10 | 1.0 | 0.5 | 0.80 | 0.90 | 0.60 | 0.40 | 0.4 | |
| Steam pressure | mpa | 0.63 | 0.6-0.8 | 0.63 | 0.6-0.8 | 0.63 | 0.63 | 0.63 | 0.63 | 0.63 | 0.63 |
| Cooling water pressure | mpa | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 |
| Controlling method | PLC | PLC | PLC | PLC | PLC | PLC | PLC | PLC | PLC | PLC | |
| Dimension(L) | mm | 12000 | 1000 | 10000 | 10000 | 8500 | 10000 | 8000 | 5700 | 5700 | 4000 |
| Dimension(W) | mm | 2900 | 2740 | 2660 | 2560 | 2980 | 2400 | 2400 | 2350 | 1800 | 2050 |
| Dimension(H) | mm | 3930 | 3660 | 4120 | 3520 | 3325 | 3580 | 3880 | 4170 | 3305 | 2795 |
