DC-18GHz 100W SMA Male Female RF Components 60dB High Power Attenuator
Price:
negotiation
MOQ:
10pcs
Delivery Time:
depends on quantity
Brand:
Vinncom
Product Description
DC-18GHz 100W SMA Male-SMA Female RF Components 60dB Attenuator
We can provide a variety of power attenuator, can quantitatively absorb the energy in the transmission line, extend the power range, control the power level, and can be equipped with a small power meter, comprehensive tester or spectrum analyzer can be accurate measure the power or spectrum of various RF microwave transmitters.
Product Features:
Wide working frequency range
Low standing wave
High attenuation accuracy
High indicator stability
| Part Number | VN-AT-18G-100W-SMA | ||||||
| Operating Frequency | DC-18 GHZ | ||||||
| Impedance ( Ohm ) | 50 | ||||||
| Application | Indoor & Outdoor | ||||||
| Degree of Protection | IP65 | ||||||
| Handling Power (Watt, max) | 100W | ||||||
| Interface | SMA Male - SMA Female | ||||||
| Operating Temperature ( ℃ ) | -40 ~ + 80 | ||||||
| Attenuation(dB) | 3 | 6~10 | 11~20 | 21~30 | 31~40 | 41~60 | VSWR |
| DC-4GHz | ±0.4 | ±0.7 | ±0.7 | ±0.8 | ±0.8 | ±1.0 | ≤1.20 |
| DC-8GHz | ±0.5 | ±0.8 | ±0.8 | ±0.9 | ±0.9 | ±1.1 | ≤1.25 |
| DC-12.4GHz | ±0.6 | ±0.9 | ±0.9 | ±1.0 | ±1.1 | ±1.2 | ≤1.35 |
| DC-18GHz | ±0.8 | ±1.5 | ±1.5 | ±1.3 | ±1.4 | ±1.4 | |
| Dimension (mm), excl connector) | 120x110x101mm | ||||||
| Net Weight (g) | / | ||||||
| Packing Dimensions (mm,L×W×H) | / | ||||||
| Packing Carton Size (mm,L×W×H) | / | ||||||
| ROHS Compliance | Yes | ||||||
| Revision | R1 | ||||||
| Date | 16-Feb-2021 | ||||||
Application
The coaxial attenuator can control the output power of the local oscillator in the microwave superheterodyne receiver to obtain the best noise figure and frequency conversion loss to achieve the best reception effect. It can also be used as a decoupling element between the oscillator and the load. Currently widely used in mobile communications, aviation, radar, scientific research, radio and television and other fields.
Company Profile
Packing & Delivery
FAQ
Q1: Are you a factory or a trade company? A1: We are factory specialised in kinds of Microwave & mmWave components.
Q2: Where are you located? A2: We are in HeFei city, near Shanghai.
Q3: How many years have you engaged in this business? A3: We have engaged in this business more than 18 years, and we are professional in Microwave components.
Q4: How long is your delivery time(lead time)? A4: Within 5 days if the product is in stock, otherwise will take about 20days, after receiving the deposit.
Q5: What’s the MOQ (Minimum Order Quantity)? A5: Generally speaking 10pcs, but it depends on models.
Q6: It is all right to add our logo on your products? A7: Yes, we can do printing logo.
Q7: Why choose us? A8: As a professional supplier for microwave components more than 10 years, we win our clients with good quality and competitive price. QC inspection before shipping, strong quality control process.
