4" SS Bag Filter Unit Industry Liquid Filtration
4" SS Bag Filter Unit Industry Liquid Filtration Stainless Steel Bag Filter
1.High filtration precision, uniform pore size filter.
2.Small filtration resistance, flux, interception capability, long service life.
3.Filter is clean and no second pollution to the filter media.
4.It also can filter acid, alkali and other chemical agents.
5.High-intensity,heat-resistant,deformation resistance.
6.Low price, low running costs, easy to clean, filter can be replaced.
Performance of stainless steel bag filter:
Filter rate:0.5-25micron,common is 1-10μm.
single filter bag type
multi filter bag type
Technology date of stainless steel bag filter:
technical parameter
design pressure:0.75—1.6Mpa
design temperature:20℃~120℃
sealing type:O ring and flat gasket
sealing material:NBR, silica gel, fluororubber and polytetrafluoroethylene, etc., are standard configured as silicone seal
conncetion type:Clamp,GB,HG,DIN,ANSI,JISstandard flange
applicable filter element:flat and 222and226 filter element
surface treatment:Matt spraying, mirror polishing, electrolytic polishing
filter rate:0.5μm--100μm
material:SUS304,316L
| Working pressure: | 0.6 / 1.0 / 1.6Mpa |
| Body Material: | Stainless steel (SUS304, SUS304L, SUS316, SUS316L). |
| Operating temperature: | 5 ~ 40 ℃ (exceed 60 ℃ to be informed) |
| Design temperature: | 5 ℃ -100 ℃ |
| Replace the pressure: | 0.05Mpa-0.07MPA |
| Filter interface: | flat compression, plug-in |
| Cylinder and base connection mode: | quick opening, flanged |
| Filtration accuracy: | 1μm ~ 100μm |
| Cartridge Quantity: | 1 core to 180 cores |
| Filter Length: | 10 "~ 40" |
| Seal type: | O-ring or flat washer |
| Seal Material: | PTFE, rubber. |
| Outside treating : | matte jet beads, mirror electrolytic polishing. |
| Sealing material: | nitrile rubber, silicone, Viton, standard configuration for the silicone seal. |
| Interface Type: | GB, HG, DIN, ANSI, JIS standard flanges, dental mouth, clamps and so on. |
| Flange Standard: | GB, HG, SH, HGJ, JB, ANSL, JIS and other standards. (User-specified, please indicate the pressure level) |
| Manufacturing, testing standard: | GB150 standard, or user-specified criteria. |
Component of stainless steel bag filter:
mainly composed of connecting pipe, filter body, filter basket, flange, flange cover and fastener.
Characteristic:
high design pressure,
filter rate≥40microns
Large filtration area, which can meet the conditions of large flow
characteristic of stainless steel bag filter:
Bag filter is a versatile filter equipment with simple and flexible operation, energy saving, high efficiency, closed work and strong applicability.
The bag filter is supported by metal net basket inside, liquid flows in from the inlet, and then flows out from the outlet after filtering by the filter bag. Impurities are intercepted in the filter bag. Can be used after replacing the filter bag.
structure of stainless steel bag filter:
Details Images of bag filter:
1.Cartridge Filter Housing
Cartridge filter, also known as security filters, generally set before the pressure vessel to remove the tiny particles whose turbidity above 1 degree, to meet the requirements of the follow-up process of water; sometimes, it is also set at the end of the entire water system to prevent small particles (such as broken resin) into the finished water.
Commonly used wound filter and meltblown filter
Wound filter (also known as honeycomb filter), there are two types: one is polyp
ropylene fiber - polypropylene skeleton filtration, the maximum temperature 60 ℃; the other is cotton fiber - stainless steel frame filter, the maximum temperature 120 ℃.
Raw material of meltblown filter is polypropylene, the maximum operating temperature is 60 ℃. Sophisticated filters can remove suspended solids, colloidal substances and some fine particulate matter and so on.
Security of stainless steel bag filter:
It is used to remove the fine substances (such as tiny quartz sand, activated carbon particles, etc.) after multi-media filtration, so as to ensure the filtration accuracy of water quality and protect the membrane filtration elements from the damage of large particles. It is mainly used after multi-media pretreatment filtration and before membrane filtration equipment such as reverse osmosis and ultrafiltration.
The housing is made of stainless steel, and the filter element (such as PP cotton, nylon, meltblown, metal, etc.) is installed inside
The filtration level of filter element can be divided into0.5μm,1μm,5μm,10μm etc.
The main advantages of security filter are high efficiency, small resistance and easy replacement.
stainless steel bag filter pictures:
