Polyester Filtration 99.4% Dia 50mm Sintered Wire Mesh Filter
Filtration accuracy 1-200μm,dia 50 mm , Powder filtration polyester filtration stainless steel powder sintered filter
Sintered filter characteristics:
Material: SS304, ss304l, SS316, SS316L
Filtration accuracy: 1 - 300 microns
Dimensions: Custom
Working temperature: - 200 - 600 ℃
Material (sintered wire mesh)
The multi-layer metal woven wire mesh is processed by vacuum sintering equipment according to the requirements, and has high mechanical strength.
Product information:
The stainless steel powder sintered filter element we provide is suitable for filtering high temperature gas up to 800°C. These include high tensile and rupture strength, high temperature resistance, and corrosion resistance
describe:
Titanium powder sintering filter (including tubesheet) is a new type of high-efficiency porous filter material made of industrial high-purity titanium powder (99.4%) by powder grading, molding, sintering, mechanical welding and other processes. Widely used in pharmaceutical, water treatment, food, bioengineering, chemical, petrochemical, metallurgy, gas purification fields. Because of its porosity and filtration accuracy, it can be adjusted in a wide range. Titanium powder sintered filter plate or filter tube is a new type of filter material, which has broad development prospects.
Characteristics:
The sintered powder filter can realize micro-scale precision filtration and separate solid particles in liquid and gas. When the fluid passes through a certain precision filter element, the impurities are blocked on the surface of the filter to form a filter cake, and the pure fluid flows out through the filter element. Clean the contaminated or contaminated fluid to the state required for normal production to ensure that downstream devices obtain clean products or protect equipment from normal operations.
advantage:
1. Strength: high mechanical strength and compressive strength.
2. Easy to clean: because the surface of filter material has cleaning characteristics, it is especially suitable for backwashing.
3. Easy to process: suitable for cutting, bending, stamping, stretching, welding and other processes.
4. High temperature: 480 ° C can withstand high temperature.
5. Corrosion resistance: due to SUS316L, 304 material corrosion resistance.
6. Filtration: the filtration range is 1 μ M-200 μ m, with reliable filtration performance.
7. Stability: because there are two layers to protect the screen, and the solid fusion diffusion sintering process, the filter screen is not easy to deform
| Specifications: | |||||||
| Filtering | Filtration | Maximum | Permeability | Permeability | Thickness | Compression | Bubbling |
| Level | Precision | Hole | Coefficient | M3/h.㎡.kpa | mm | Strength | Pressure |
| um | Diameter um | 10~12㎡ | Mpa/cm2 | Kpa | |||
| S9 | 0.2 | 2.5 | 1 | 0.6~10 | 3 | ||
| S8 | 0.5 | 4 | 3 | 0.6~10 | 3 | ||
| S7 | 1.5 | 6 | 5 | 0.6~10 | 3 | ||
| S6 | 2.5 | 10 | 0.09 | 10 | 0.6~10 | 3 | 9.16 |
| S5 | 5 | 15 | 0.23 | 40 | 0.6~10 | 3 | 6.1 |
| 8 | 20 | 0.91 | 80 | 0.6~10 | 3 | 4.6 | |
| S4 | 10 | 30 | 1.81 | 160 | 0.6~10 | 3 | 2.6 |
| S3 | 28 | 60 | 3.82 | 350 | 0.6~10 | 3 | 1.8 |
| 35 | 80 | 7.29 | 500 | 0.6~10 | 3 | 1.4 | |
| S2 | 40 | 100 | 9.43 | 700 | 0.6~10 | 3 | 1.1 |
| S1 | 65 | 160 | 15.1 | 1000 | 0.6~10 | 3 | 0.66 |
