Melt Filtration 1 Micron 200μM Wire Mesh Filter Disc
Filtration accuracy is 1-200 m , high viscosity melt filtration disc filter
Disc filter Basis Information
Disc filter is usually is made by Sintered mesh. It is excellent filters for filtration, cleaning and drying.
Hanke Filter can be customized by your demands
| Type | D(mm) | Filter Area | Rating | Filter Media |
| DF-600-R | 600 | 0.28㎡ | 5,10,15,20,30,40,60 | SS sintered mesh |
| DF-800-R | 800 | 0.50㎡ | Thickness: | |
| DF-1000-R | 1000 | 0.79㎡ | 1.7mm | |
| DF-1200-R | 1200 | 1.13㎡ | 2.5mm | |
| DF-1600-R | 1600 | 2.01㎡ | 3.5mm | |
| DF-1800-R | 1800 | 2.54㎡ | ||
| DF-2000-R | 2000 | 3.14㎡ | ||
| DF-2300-R | 2300 | 4.15㎡ | ||
| DF-2400-R | 2400 | 4.52㎡ | ||
| DF-2600-R | 2600 | 5.13㎡ | ||
| DF-2750-R | 2750 | 5.94㎡ | ||
| DF-2800-R | 2800 | 6.15㎡ | ||
| DF-3000-R | 3000 | 7.06㎡ |
Disc filter technology:
Filtration rate: 1-200μm
OD: 380-3000mm
Structure: unibody or split-body
Disc filter medium:
stainless steel sintered fiber web, stainless steel wire mesh, wire cloth, phosphate copper wire mesh, copper wire mesh, brass wire mesh, galvanized square wire mesh, etc.
Disc filter Advantage:
-High hardness, High strength, High-durability
-Long working life
-Easy to clean
-Easy for installation
Disc filter Applications:
Filter discs are mainly used in the absorption, evaporation and filtration process in petroleum, chemical, medicine, metallurgy, machinery, ship and automobiles to delete the mist drop or liquid foam or used as air filter in cars and trucks.
