Candle Purifier 1000×500mm 1000×600mm Sintered Wire Mesh Filter
Candle Purifier 1000×500mm 1000×600mm Sintered Wire Mesh Filter
Sintered filter characteristics:
Material: SS304, ss304l, SS316, SS316L
Filtration accuracy: 1 - 300 microns
Dimensions: Custom
Working temperature: - 200 - 600 ℃
Specification:
Properties of sintered metal Fiber felt:
1 Standard material: 316L stainless steel
2 Standard size: 1000×500mm 1000×600mm
1000×1000mm 1200×1000mm 1500×1200mm
three. Customized service:
Size and material can be customized according to needs
User needs.
Special production requirements: reinforcement, thickening,
Steel mesh
| Model | L (mm) | D (mm) | M | Filter Area(M2) | R (µm) | Filter Media |
| CF-50/250-R | 250 | 50 | Sealing ring or flange | 0.038 | 2, 5, 10, 15, 20, 30, 40, 75 | Stainless Steel Sintered Wire Cloth |
| CF-50/500-R | 500 | 0.078 | ||||
| CF-50/1000-R | 1000 | 0.15 | ||||
| CF-60/500-R | 500 | 60 | 0.094 | |||
| CF-70/500-R | 500 | 70 | 0.108 | |||
| CF-75/500-R | 500 | 75 | 0.115 | |||
| CF-90/500-R | 500 | 90 | 0.14 | |||
| CF-150/500-R | 500 | 150 | 0.23 | |||
| Note: Inner support of filter elements can be stainless steel perforated tube or spring | ||||||
Specification of stainless steel sintering mesh:
1. Material: SUS316L, SUS304, sus904l, alloy20,
Hastelloy, Monel, Inconel
2. Supply size: ≤ 1500 × 1000mm
3. Filtering accuracy: 1 ~ 300 μ M
4. Standard five layer sintering net, including:
5. Reinforcement layer
6. Reinforcement layer
7. Separation layer
8. Filter layer
9. Protection
Technology:
Compressed by powder in a mold and sintered at high temperature
Temperature, Nali formed a whole, Filson
The porous metal filter has high
High mechanical strength, high temperature resistance, good performance
Corrosion resistance, uniform hole distribution, welding
Mechanical processing, etc.
Advantage:
-Uniform hole, accurate filtration rate
-High hardness and good abrasion resistance
-Excellent resistance to erosion, heat and pressure
Application:
-Polyester
-Petrochemical, petroleum refining
-Pharmaceutical and food refining or cycling
-Drinking
-Catalytic recycling
Our Service
1. OEM Manufacturing welcome: Product, Package...
2. Sample order
3. We will reply to you for your inquiry in 24 hours.
4. after sending, we will track the products for you once every two days, until you get the products. When you got the goods, test them, and give me feedback. If you have any questions about the problem, contact us, we will offer the solve way for you.
5.Sample testing support.
6.Changing for new if dissatisfaction.
