Pressure Resistant 35mm 1500mm Corrugated Mesh Filter Element
high pressure resistant , 35-1500 - mm length Corrugated mesh filter element
Application parameters:
Working pressure: 30MPa
Working temperature: 600 ℃
Fluid viscosity: 260pa. trumpet
Reception: 16.9-41mg / C M2
Filtration accuracy: 3-300 μ M
| Model | L (mm) |
D (mm) |
M | Filter Area (M2) |
R (µm) |
Filter Media |
| PF-86/200-R | 200 | 86 | M65x2P | 0.20 | 3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75 | SS sintered fiber wed, SS wire cloth |
| PF-86/350-R | 350 | 0.35 | ||||
| PF-86/500-R | 500 | 0.50 | ||||
| PF-100/800-R | 800 | 100 | M80x2P | 1.00 |
| Model | L (mm) |
D (mm) |
M | Filter Area (M2) |
R (µm) |
Filter Media |
| PF-65/250-R | 250 | 65 | 226 223 220 215 |
0.135 | 3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75 | SS sintered fiber wed, SS wire cloth |
| PF-65/500-R | 500 | 0.38 | ||||
| PF-70/750-R | 750 | 70 | 0.42 | |||
| PF-70/750-R | 750 | 0.60 |
| Model | L (mm) |
D (mm) |
M | Filter Area (M2) |
R (µm) |
Filter Media |
| PF-35/102-R | 102 | 35 | M18 M20*2.5 M20*1.5 NPT1" 3/4 - 16 |
0.026 | 3, 5, 7, 10, 15, 20, 25, 30, 40, 60, 75 | SS sintered fiber wed, SS wire cloth |
| PF-35/207-R | 207 | 0.07 | ||||
| PF-35/210-R | 210 | 0.07 | ||||
| PF-35/242-R | 242 | 0.08 | ||||
| PF-35/425-R | 425 | 0.15 | ||||
| PF-35/485-R | 485 | 0.20 |
Advantage:
1 There is a wave pattern, the area is increased several times, the dirt holding capacity is stronger, and the replacement cycle is longer.
2 High porosity, strong air permeability, low pressure, suitable for filtration of high viscosity media.
three. Has excellent strength, high temperature resistance and corrosion resistance.
4 Good repeatability, chemical cleaning, calcination, ultrasonic cleaning can be used repeatedly.
Feature:
High porosity, good air permeability, low resistance, low pressure
High temperature resistance, corrosion resistance, suitable for high viscosity liquid filtration
Good repeatability, chemical cleaning, high temperature cleaning, ultrasonic cleaning can be reused
All stainless steel structure, good chemical compatibility
High pollution retention capacity
Disposable components and cleanable components
Fold elements
Flow direction from outside to inside to maximize stability
Due to the support of solid filter material, it has excellent flow fatigue stability
Standard filtration grade: 3μm, 5μm, 10μm and 20μm absolute value
Application:
1. Petrochemical: oil refining, chemical production and separation and recovery of intermediate products
2. Metallurgy: hydraulic system for filtering mill and caster
3. Textiles: purification and uniform filtration of polyester melt during stretching
4. Electronics and pharmacy: pretreatment and filtration of reverse osmosis water and deionized water, pretreatment and filtration of cleaning solution and glucose
5. Thermal power and nuclear power: oil purification in lubrication system, speed control system and bypass control system of gas turbine and boiler, purification of feed pump, fan and dust removal system
