30x30cm Aerospace Stainless Steel Square Wire Mesh Sheet
Stainless Steel 304 Wire Mesh, 30x30cm Square Sheet (10 mesh)
Stainless Steel Wire Mesh – Twill Weave
For heavier needs, the twill weave is recommended. The shute wire is passed above and under two warp wires ensuring that the weave is sturdier as this produces a stronger and more durable wire mesh. The warp and weft have the same diameters thus creating a close diagonal pattern. This type of pattern is mostly used for filtration.
Applications:
Sizing
Separation and Filtration
Sifting of particles
In safety and equipment protection
Aerospace
Automotive
Construction
Oil and Gas
| Mesh/inch | Wire Dia. | Aperture Size(um) | Open Area (%) | Thickness | Through ink(mm³/m) | Material |
| 40*40 | 160 | 475 | 56 | 300-320 | 179.1 | 316L/304N |
| 50*50 | 140 | 368 | 52 | 265-280 | 146.9 | 316L/304N |
| 60*60 | 120 | 303 | 51 | 230-245 | 123.2 | 316L/304N |
| 70*70 | 70 | 293 | 65 | 135-143 | 91.2 | 316L/304N |
| 80*80 | 120 | 198 | 39 | 235-245 | 92.9 | 316L/304N |
| 80*80 | 90 | 228 | 52 | 175-180 | 93.1 | 316L/304N |
| 80*80 | 50 | 268 | 71 | 95-100 | 71 | 316L/304N |
| 100*100 | 100 | 154 | 37 | 195-205 | 77.2 | 316L/304N |
| 120*120 | 80 | 132 | 39 | 155-165 | 65.8 | 316L/304N |
| 150*150 | 60 | 109 | 42 | 115-124 | 50 | 316L/304N |
| 165*165 | 35 | 119 | 60 | 70-75 | 48 | 316L/304N |
| 165*165 | 45 | 109 | 50 | 88-93 | 45.1 | 316L/304N |
| 165*165 | 50 | 104 | 46 | 97-105 | 45.6 | 316L/304N |
| 180*180 | 45 | 96 | 48 | 88-93 | 41.5 | 316L/304N |
| 180*180 | 50 | 91 | 42 | 96-104 | 41.7 | 316L/304N |
| 200*200 | 40 | 87 | 47 | 78-82 | 37.5 | 316L/304N |
| 200*200 | 50 | 77 | 37 | 98-103 | 36.8 | 316L/304N |
| 230*230 | 35 | 75 | 46 | 58-61 | 28.8 | 316L/304N |
| 250*250 | 40 | 62 | 37 | 69-74 | 23.2 | 316L/304N |
| 250*250 | 30 | 72 | 50 | 58-62 | 29.8 | 316L/304N |
| 250*250 | 35 | 67 | 43 | 64-68 | 31.2 | 316L/304N |
| 270*270 | 35 | 59 | 40 | 71-75 | 30.1 | 316L/304N |
| 300*300 | 30 | 55 | 42 | 65-69 | 28.8 | 316L/304N |
| 325*325 | 30 | 48 | 38 | 62-66 | 28.2 | 316L/304N |
| 325*325 | 28 | 50 | 41 | 60-64 | 26.4 | 316L/304N |
| 325*325 | 23 | 55 | 50 | 49-53 | 25.4 | 316L/304N |
| 350*350 | 25 | 48 | 43 | 46-49 | 18.7 | 316L/304N |
| 360*360 | 16 | 55 | 60 | 31-35 | 21.5 | 316L/304N |
| 400*400 | 23 | 41 | 41 | 50-54 | 22 | 316L/304N |
| 400*400 | 18 | 46 | 51 | 36-40 | 19.5 | 316L/304N |
| 500*500 | 18 | 33 | 42 | 36-40 | 15.3 | 316L/304N |
| 500*500 | 15 | 35 | 47 | 33-37 | 12 | 316L/304N |
| Plain Dutch woven: | |||||
| Mesh/Inch (warp×weft) |
Wire Dia. warp×weft(mm) |
Normal size(μm) |
Effective area% | Weight kg/sq.m |
Cloth thickness (mm) |
| 7×44 | 0.71×0.63 | 319 | 14.2 | 5.55 | 1.97 |
| 8×45 | 0.8×0.6 | 310 | 15.5 | 5.7 | 2 |
| 8×60 | 0.63×0.45 | 296 | 20.3 | 4.16 | 1.53 |
| 8×85 | 0.45×0.315 | 275 | 27.3 | 2.73 | 1.08 |
| 10×90 | 0.45×0.28 | 249 | 29.2 | 2.57 | 1.01 |
| 10×76 | 0.5×0.355 | 248 | 21.8 | 3.24 | 1.21 |
| 12×86 | 0.45×0.315 | 211 | 20.9 | 2.93 | 1.08 |
| 12×64 | 0.56×0.40 | 211 | 16 | 3.89 | 1.36 |
| 12×76 | 0.45×0.355 | 192 | 15.9 | 3.26 | 1.16 |
| 14×100 | 0.40×0.28 | 182 | 20.3 | 2.62 | 0.96 |
| 14×110 | 0.4×0.25 | 177 | 22.2 | 2.28 | 0.855 |
| 14×76 | 0.45×0.355 | 173 | 14.3 | 3.33 | 1.16 |
| 16×100 | 0.40×0.28 | 160 | 17.7 | 2.7 | 0.96 |
| 17×120 | 0.355×0.224 | 155 | 22.4 | 2.19 | 0.803 |
| 16×120 | 0.28×0.224 | 145 | 19.2 | 1.97 | 0.728 |
| 20×140 | 0.315×0.20 | 133 | 21.5 | 1.97 | 0.715 |
| 20×170 | 0.25×0.16 | 130 | 28.9 | 1.56 | 0.57 |
| 20×110 | 0.355×0.25 | 126 | 15.3 | 2.47 | 0.855 |
| Twill dutch woven | |||||
| Mesh/Inch (warp×weft) | Wire Dia. warp×weft (mm) | Normal size (μm) | Effective(area%) | Weight kg/sq.m | Cloth thickness (mm) |
| 20×270 | 0.25×0.2 | 119 | 17.6 | 3.14 | 0.65 |
| 20×200 | 0.355×0.28 | 118 | 12.1 | 4.58 | 0.915 |
| 24×300 | 0.28×0.18 | 110 | 19.6 | 3.01 | 0.64 |
| 20×150 | 0.45×0.355 | 101 | 7.5 | 6.02 | 1.16 |
| 30×340 | 0.28×0.16 | 89 | 17.9 | 2.84 | 0.6 |
| 30×270 | 0.28×0.20 | 77 | 11.2 | 3.41 | 0.68 |
| 40×540 | 0.18×0.10 | 70 | 23.5 | 1.73 | 0.38 |
| 40×430 | 0.18×0.125 | 63 | 15.4 | 2.09 | 0.43 |
| 50×600 | 0.125×0.09 | 51 | 17.2 | 1.47 | 0.305 |
| 50×500 | 0.14×0.11 | 47 | 12 | 1.83 | 0.364 |
| 65×600 | 0.14×0.09 | 36 | 1.59 | 0.32 | |
| 70×600 | 0.14×0.09 | 31 | 10.1 | 1.61 | |
| 78×760 | 0.112×0.071 | 13.5 | 1.25 | 0.254 | |
| 78×680 | 0.112×0.08 | 29 | 10.3 | 1.37 | 0.272 |
| 80×680 | 0.112×0.08 | 28 | 9.8 | 1.38 | |
| 90×850 | 0.10×0.063 | 26 | 12.7 | 1.12 | 0.226 |
| 90×760 | 0.10×0.071 | 24 | 9.6 | 1.23 | 0.242 |
We owned
Preeminent research&Development team;
Advanced design ideas;
20 years’ experience;
Standardized production equipment;
Effective quality management
Products
Pleated filter,sintered filter element,filter disc and various filter elements and wire mesh.The material include stainless steel,duplex SS,Supper Duplex SS,monel,inconel,nickel,hastelloy etc.
Application
Petro-chemical,Polymer,Catalytic filtration,fuel filtration,oil pressure production line and cutting oil filtration and homogenization;Gas treatment;water treatment;pharmaceutical industries,food industries;industrial flame protection,etc.
