Woven 300 Micron Nichrome Wire Mesh For Shipbuilding Nickel Alloy Wire Mesh
Woven 300 Micron Nichrome Wire Mesh For Shipbuilding Nickel Alloy Wire Mesh
Nickel Alloy Wire Mesh Characteristics
Nichrome is the alloy of nickel and chrome. According to different chemical composition, nichrome can be divided into Cr20Ni80, Cr15Ni60 and Cr20Ni35.
Nichrome woven wire mesh is made of the nichrome wire, which is woven into regular meshes. Nichrome woven wire mesh has outstanding ductility, high tensile strength, oxidation resistance, sulfur resistance and other features.
Equipped with so many features, nichrome woven wire mesh has a wide range of applications, including the aerospace, shipbuilding, military industry, chemical and other fields.
Nickel Alloy Wire Mesh Chemical composition
| Grade | % | Ni | Cr | Fe | Al | Mn | Si | C | P | S |
|---|---|---|---|---|---|---|---|---|---|---|
| Cr20Ni80 | Min. | Bal. | 20 | - | - | 0.6 | 0.75 | 0.08 | 0.02 | 0.08 |
| Max. | 23 | 1.0 | 0.2 | 1.6 | ||||||
| Cr15Ni60 | Min. | 55 | 15 | Bal. | - | - | 0.75 | 0.08 | 0.02 | 0.15 |
| Max. | 61 | 18 | 0.5 | 0.6 | 1.6 | |||||
| Cr20Ni35 | Min. | 34 | 18 | Bal. | - | 1 | 1 | 0.1 | 0.03 | 0.025 |
| Max. | 37 | 21 | 0.5 | 3 |
Nickel Alloy Wire Mesh Specifications
- Material: Cr20Ni80, Cr15Ni60 and Cr20Ni35.
- Weaving type: plain weave and twill weave.
- Wire diameter: 0.0014" - 0.063".
- Mesh size: 4 mesh - 325 mesh.
- Width: 0.1m - 1.5m.
- Length: commonly is 30m. Other specs can be customized.
| Item | Mesh (Wires/ in.) | Wire diameter (in.) | Width of opening (in.) | Open area (%) |
|---|---|---|---|---|
| RNC-01 | 4 × 4 | 0.063 | 0.1870 | 56.00 |
| RNC-02 | 8 × 8 | 0.047 | 0.0780 | 38.90 |
| RNC-03 | 8 × 8 | 0.025 | 0.1000 | 64.00 |
| RNC-04 | 10 × 10 | 0.035 | 0.0650 | 42.30 |
| RNC-05 | 16 × 16 | 0.020 | 0.0430 | 46.20 |
| RNC-06 | 20 × 20 | 0.020 | 0.0300 | 36.00 |
| RNC-07 | 20 × 20 | 0.013 | 0.0370 | 54.80 |
| RNC-08 | 20 × 20 | 0.016 | 0.0340 | 43.20 |
| RNC-09 | 26 × 26 | 0.013 | 0.0260 | 44.00 |
| RNC-10 | 40 × 40 | 0.010 | 0.0150 | 36.00 |
| RNC-11 | 40 × 40 | 0.0070 | 0.0180 | 51.80 |
| RNC-12 | 80 × 80 | 0.0055 | 0.0070 | 31.40 |
| RNC-13 | 200 × 200 | 0.0021 | 0.0029 | 33.60 |
| RNC-14 | 325 × 325 | 0.0014 | 0.0017 | 29.70 |
Nickel Alloy Wire Mesh Features
- Good ductility.
- High tensile strength.
- Oxidation resistance.
- Sulfur resistance.
- Permeability resistance.
- Superior elongation.
- Non-magnetic.
Nickel Alloy Wire Mesh Applications
Nichrome woven wire mesh is widely used in the aerospace, shipbuilding, war industry, chemical machinery, electric power, desalination, medical apparatus and instruments.
Package
- Paper tube.
- Brown paper.
- Plastic film.
- Wooden box.
Nickel Alloy Wire Mesh Delivery:
