75 Micron Rating Metal Mesh Filter Pet Resin Recovery Ss304 Pleated
75 Micron Filter Rating PET Resin Recovery SS304 Pleated Wire Mesh Filter
Stainless Steel Pleated Filter Element Information:
Stainless steel sintered fiber felt is a honey comb filter hole with high filtration rate. And it is a kind of durable and pleating-able, enough pleating can get bigger filtration area. Sintered into a graded pore structure, enjoys the advantages of high porosity rate, more filtration area, high dirt holding capacity and can be repeatedly used.
Stainless Steel Pleated FilterTechnical:
• Filtration rate: 3- 200μm;
• Work Temperature: -50℃-800℃;
• Size: 25-180mm OD, 100-1500mm Length
• Hanke Filter can be customized.
Stainless Steel Pleated Filter Application:
• Polymer filtration
• Water treatment
• Oil filter
• Chemical industry
• Medicine
• Metallurgy
• Food machinery
Stainless Steel Pleated Filter Parameters:
| Model | Length | Diameter | M | Filter Area |
Filter Rate (μm) |
Filter Material |
| PF-60/400-R | 400 | 60 | M33x1.5PM33x2P | 0.4㎡ |
3,5,7,10,15,25, 30,40,60,75 |
Stainless Steel Sintered Fiber Mesh, Stainless Steel Wire Cloth |
| PF-60/500-R | 500 | 60 | 0.5㎡ | |||
| PF-60/1000-R | 1000 | 60 | 1.00㎡ |
