Capacity 20000L SINOTRUK HOWO 6x6 336hp All Wheel Drive Diesel Tanker Truck
SINOTRUK HOWO 6x6 All Wheel Drive Fuel Tanker Truck Capacity 20,000 Liters
Fuel Tanker is widely used in oil industry for fuel transportation, refueling and storage, etc.
Fuel truck also called fuel bowser, fuel tank truck, fuel tanker, oil tanker, oil tank truck, petrol tank, petrol fuel tank, tanker truck, refueler truck , petroleum tanker, fuel dispenser truck, fuel dispensing truck, mobile dispenser truck, crude oil truck, crude oil tanker truck, fuel transport truck, diesel truck, mobile diesel tanker truck.
It can be divided into many compartments to transport different medium, which will make your transportation easy and safe.
Chassis: SINOTRUK 6x6 all wheel drive which is more powerful for desert or very bad rough condition road.
Tanker: 20,000 liters, 4 compartments, 5000 liters each compartment.
Our company are professional manufacturer in truck area, guarantee all goods Brand-New and China-Origined. We can provide you all series tank trucks and price.
Tank materials: Optional for carbon steel, stainless steel, rotational lining plastic, and FRP;
Tank shape: Optional for round square, oval, and round;
Functions: The tank can be made to be made to be separated chambers to load different oil or chemical varieties .and can be designed as as pump-in and pump-out through measurement;
Oil pump:Optional single counting, double counting, and tax control tanker;
Pump: According to the use of tankers, can choose centrifugal pumps, gear pump, copper gear pump, stainless steel pump, it has big flow,fast speed of suction and some other characteristics.
Specification
| Model | ZZ2257N4657A | |
| Cabin | HW76, with two seats and one bed, A/C and electric window. | |
|
Engine |
Model | WD615.69 |
| Horse Power (Hp/rpm) | 336/2200, Euro II Emission Standard | |
| Max.Toruqe(Nm/rpm) | 1350/1100-1600 | |
| Displacement ( L) |
9.726 |
|
| Type | 6-cylinder in-line with water cooling, turbo charger and intercooling, 4- stroke direct injection diesel engine | |
| Transmission | HW19710, 10 speeds forward and 2 speeds reverse. | |
| Front Axle | HF9, Steering with double T-cross section beam, Loading Capacity: 9,000kgs | |
| Driving Axle | HC16, Pressed axle housing, central reduction with hub reduction, with differential locks between wheels and axles. ratio: 4.8. Option: 4.42 | |
| Suspension | Front suspension: hydraulic telescopic double-action shock absorbers and stabilizer; Rear suspension: leaf semi-elliptic springs, bogie spring and stabilizer | |
| Steering System | ZF8118, Hydraulic steering with power assistance | |
| Brake System | Service brake: Dual circuit compressed air brake; Parking brake (emergency brake): Spring energy, compressed air operating; Auxiliary brake: Engine exhaust brake | |
| Tire | 12.00R20 | |
| Fuel Tank Capacity (L) | 400L Diesel Tank | |
| Curb Weight (kg) | 13,000 | |
| Loading Capacity (kg) | 26,000 | |
| Gross Vehicle Weight (kg) | 39,000 | |
| Overall Dimension(L*W*H) (mm) | 10200×2500×3310 | |
| Tank Capacity(L) | 20,000 | |
| Tank Material | Carbon Steel | |
| Compartments | 4 | |
| Wheelbase(mm) | 4625+1350 | |
| Max. Speed (km/h) | 90 | |
Pictures
