Lotus Plug T Bar 16Ah 24Ah 12 Volt Lithium Battery For Golf Cart
Lotus Plug T Bar 16Ah 24Ah 12 Volt Lithium Battery For Golf Cart
Wholesale price 12V 16Ah/18Ah/22Ah/24Ah golf lithium battery with T-bar and charger
MaxLi battery is a full qualified manufacturer of high standard lithium battery under a wide range of specs.
12V Golf trolley batteries are one of our top-rated products with built-in smart BMS..MaxLi smart BMS(Battery Management System)in each battery will detect any problems with the performance of the battery and shurt down any cells not functioning properly, offers 8 different protection modes:
Over charge detection function
Over discharge detection function
Current detection
Temperature protection
Short circuit detection
Balance function
MaxLi 12V golf lithium batteries,Drop-in lead acid battery for your golf trolley.Same size as you current lead-acid batteries which allow you to convert your vehicle from lead acid battery to lithium in less than 30mins. MaxLi golf batteries meet all kinds of golf trolley.
Simply remove the lead-acid batteries and replace with the Allied Lithium Batteries, attach cables in parallel, secure holding bracket, and the install is complete.
| Model No. | Golf trolley 1-BT |
| Nominal Voltage | 12.8V |
| Nominal Capacity @ 0.2C | 18Ah |
| Watt-Hour | 230.4Wh |
|
Dimensions Length Width Height |
168mm 128mm 76mm |
| Weight | 2.18Kg |
| Internal Resistance | ≤50mΩ @ 50% SOC |
| Recommended Charge Current | 3A |
| BMS Maximum Charge Current | 20A |
| Charge Cut-off Voltage | 14.6V |
| BMS Maximum Continuous Discharge Current | 25A |
| Peak Discharge Current | 40A (3S) |
| Discharge Cut-off Voltage | 10.0V |
| Expected Cycle Life | ≥3000 cycles at 0.2C/0.2C, 80% DoD |
| Self Discharge | <3% per month |
| Cell Type | Cylindrical 32700 6.0Ah |
|
Operating Temperature Charge Discharge Storage |
0 - +55°C -20 - +60°C -5 - +35°C |
| Humidity | RH≤85% |
| Case Material | ABS |
| Terminal | Lotus Plug(charge) T-Anderson connectors(discharge) |
| Communication Interface |
MaxLi battery is a full qualified manufacturer of high standard lithium battery under a wide range of specs.
A wholly-own factory located in DongGuan city with multi professional productions lines:
Raw material details as followings:
Well packaged with UN standard high quality carton and 25mm thickness foam:
FAQ
A1:Yes,we can supply samples,the leadtime for samples is 7-10 days after the payment.
Q2: Do you provide after-sales serive?
A2: Yes,every MaxLi battery has 3 years manufacturer warranty, if any quality issues in this period, we can send new one as replacement.
Q3 What is your company's advantage?
A3: MaxLi battery specilizes in research,development and production of lithium battery pack(LiFePO4+NCM) for years,with professional B&D team dedicated in design cost efficent and market-oriented products.
Q4: Do you accept OEM/ODM?
A4: Yes,it is avaliable.
Q5: What is your lead time for the mass production?
A5: With more than 6 professional production lines,our daily output reach by more than 2000packs battery packs,normally one 20'container 12V 100Ah just need within 20-25days with full strict aging test.
Q6:Are you battery real capacity?
A6:All of our battery cells with Grade A,100% new and real capacity.Every battery will have an unique barcode for full strict aging test to make sure the full capacity before shipping.
Q7:Are you a factory or a trading company?
A7:MaxLi battery Ltd is a professional rechargeable lithium-ion battery and LifePO4 battery manufacturer, A wholly-owned factory located in Dongguan city by more than 4000 square meters and completed equipments,welcome to visit.
Q8: What kind of certificates do you have?
A8: We can provide CE,ROHS,ISO,FCC,IEC62133,MSDS,UN38.3 is available there.
