Hot Forging 1500mm Sae1045 Sae4340 Large Sized Steel Seamless Ring
Price:
20usd to 1500usd
MOQ:
1 pc
Delivery Time:
7-25 working days
Brand:
Golden
Product Description
|
|
 |
Hot Forging Out diameter 1500mm SAE1045 SAE4340 Sae4140 Rolled Steel Seamless Ring
Delivery Standards & sizes:
- OD from 180mm to 3000mm and more for carbon, alloy and stainless steel
- OD 180 to 3000mm for nickel alloys (alloy 400, monel, alloy 625) and 17-4PH
- Face height up to 1500mm
- According to ASTM/ASME
Main use:
- Pressure vessel and heat exchanger manufacturing
- Slewing rings
- Wind tower flanges
- Heat exchanger manufacturing
- Machine construction, forged sleeves
- Oilfield equipment
- Valve manufacturing
Forged seamless rings up to 2000mm OD and 500mm face height can be manufactured contoured rolled /profiled to save material and machining costs.
Materials:
High yield steels, carbon steels, stainless steels, duplex steels, alloy steels, nickel alloy steels,
All seamless rolled rings can be supplied with weld overlay inclusive Titanium, accordingt o your specifications
The strict use of high quality raw material is guaranteed and proved by raw material certificate with each delivery.
| Item | Process | Facility |
Inspection items
|
Standard |
|---|---|---|---|---|
01 |
Steel material inspection |
Chemical composition (EF+LF+VD) |
Material standard | |
| surface | Ingot inspection specification |
|||
| Ingot type and weight | Material standard | |||
| 02 | Material store |
Division put | warehouse management | |
| 1 | Heat | Heat furnace | Temperature/Time | Heating process specification Forging production procedure |
| 2 ↓ |
Forging | Press | Reduction ratio,forging temperature,deformation, Surface and dimensions |
Forging process card Forging procedure |
| 3 ↓ |
Heat treatment | heat treatment furnace |
heat treatment charts | 1st heat-treatment card Forging procedure |
| 4 ↓ |
Rough inspection |
Dimensions, apperance, Mark |
Inspection specification Forging procedure |
|
| 5 ↓ |
Rough UT | UT equipment | Single defect, concentrated Defects bottom wave attenuation |
UT standard or customer's technical requirements |
| 6 ↓ |
Saw cutting | Saw machine | Dimension | IQC and forging |
| 7 ↓ |
rough turning | turning-lathe | Dimension,appearance | Rough machining drawing |
| 8 ↓ |
UT | UT equipment | Single defect, concentrated defects bottom wave attenuation |
UT standard or customer's technical requirements |
| 9 ↓ |
Q+T heat treatment |
heat treatment furnace |
heat treatment charts | Heating process specification |
| 10 ↓ |
Sampling or machining | machining tool | rough machining drawing sampling drawing |
sample machining drawing |
| 11 ↓ |
mechanical property test |
tensile testing machine/ impact testing machine |
ambient temperature,humidity, Test temp.Sample dimension, test method |
Standard technical specification |
| 12 ↓ |
finish machining |
machining tool |
Dimension,appearance | finish machining drawing |
| 13 ↓ |
UT | UT equipment | Single defect, concentrated Defects bottom wave attenuation |
UT standard or customer's technical requirements |
| 14 ↓ |
MT | MT equipment | Magnetic particle indication |
Test standard or Technical requirements |
| 15 ↓ |
Mark | Steel seal | marking content | Product standard Technical requirements Forging process |
| 16 ↓ |
Final inspection |
Appearance, dimension, mark acceptance inspection |
Product inspection specification Product standard P.O. |
|
| 17 | Protection/ package |
Blasting Blasting equipment |
appearance coating thickness |
Product standard Technical requirements |
