Welding Inverter 1.5kva Inverter Sug Inverter 5500w Inverter 5kw Inverter Hybrid Sug Hybrid Inverter
Price:
$370-$373
MOQ:
1pcs
Delivery Time:
15-20days
Brand:
SUG
Product Description
Welding Inverter 1.5kva Inverter Sug Inverter 5500w Inverter 5kw Inverter Hybrid Sug Hybrid Inverter
Artificial intelligence chips, high quality chips designed by our engineers, ensure stability and safety, high voltage capacitors, long service life.
| Model | SGPE6000-241 | SGPE6000-242 | SGPE6000-481 | SGPE6000-482 |
| Rated Power | 6000W | |||
| Surge Power | 12000W(few seconds) | |||
| Input Voltage | 24VDC | 48VDC | ||
| Output Voltage | 110VAC±5% | 220VAC±5% | 110VAC±5% | 220VAC±5% |
| USB Port | 5VDC | |||
| Frequency | 50Hz±3 or 60Hz±3 | |||
| Output Waveform | Pure Sine Wave | |||
| Soft Start | YES | |||
| AC Regulation | THD<3%(Linear Load) | |||
| Output Efficiency | 94% MAX | |||
| No Load Current | 1.6A | 0.8A | ||
| DC Voltage Range | 20-31V | 40-61V | ||
| Low Voltage Alarm | 21±0.5V | 42±1V | ||
| Low Voltage Shut Down | 20±0.5V | 40±1V | ||
| Low Voltage Recovery | 24±0.5V | 48±1V | ||
| Over Voltage Shut Down | 31±0.5V | 61±1V | ||
| Over Voltage Recovery | 29V±0.5V | 59V±1V | ||
| Cooling Way | Intelligent Cooling Fan | |||
| Protection | Battery Low Voltage & Over Voltage, Over Load, Over Temperature | |||
| Working Temperature | -10ºC - +50ºC | |||
| Net Dimension | 58.5*21.6*15.6cm (L×W×H) | |||
| N.W./Unit | 15.2kg | |||
| G.W./Ctn | 17.5KGS | |||
| Packing | Honeycomb carton | |||
| Warranty |
2 Years |
|||
