Building Material Plant Caron Steel Dissolved Air Flotation DAF Water Treatment Equipment

DAF-002 Edi CE Hotels Building Material Shops Manufacturing Plant Flocculation Reaction Dissolved Air Flotation

Dissolved air flotation machine is mainly for solid-liquid or liquid-liquid separation. Large sum of micro bubbles produced by dissolving and releasing system adhere to solid or liquid particles with same density as waste water to make the whole float to the surface thus achieve the aim of solid-liquid or liquid-liquid separation.

Air was dissolved into water, the air -saturated water generated from dissolved air micro bubbles attach to the surface of solids, The light of solids(less dense than water) lifting them to the surface. distributed over the whole tank width , Make sure optimum phase separation. Mechanical skimmer remove the floating sludge layer and the purified wastewater discharges to sewer.

Dissolved Air Flotation Equipment Specifications

Main Process Characteristics

• Small footprint, Low energy consumption; Easy operation; Simple management;

• Efficient dissolved air; Stable treatment effect ; Full-automatic operation;

• Dissolved Air Systerm is used in this device. It has ingenious structure, and its efficiency of dissolving air is as high as 90%. But its volume is only one-fifth of the other kind of dissolved air system. In addition, it still has the super anti-clogging ability which is incomparable;

• Release effect and the mean diameter of microbubble is only between 15 to 30 microns. In addition that,this kind of dissolved air releasers also has the self-cleaning ability;

• This device also applies Chained Scum Skimmer, works Smooth and reliably and skims scum efficiently.

Application Of Dissolved Air Flotation

• Meat, poultry, and fish processing

• Dairy industry

• Petrochemicals

• Pulp and paper

• Food and beverage
