Full Color 3840Hz P2.97 Indoor Rental LED Display With 500x1000mm Cabinet
Indoor Led Screen P2.97 Led Video Wall Rental Use 500x1000 Cabinet
1. All panels have high strength corner protectors, protect led lamp from damage during transportation and installation.
2. High refresh rate, >3840Hz, which makes the picture much vivider.
3. Convenient maintenance --- module front & rear service.
4. Independent power supply box without wire, easy to take off the power supply and receiving card.
5. Support curve connection --- ±2.5°&5° concave & converse connection.
| Item | Parameter | ||||
| Module specifications | Mode | p2.604 | p2.97 | p3.91 | p3.91 |
| Module size | 250*250 | 250*250 | 250*250 | 250*250 | |
| Module pixel | 96*96 | 84*84 | 64*64 | 64*64 | |
| scan | 1/32 | 1/28 | 1/16 | 1/16 | |
| Pixel configuration | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | |
| LED | SMD1515 | SMD1515 | SMD2121 | SMD2121 | |
| Max power consumption (W/piece) | 40W | 40W | 40W | 40W | |
| Mask | have | have | have | have | |
| Main Specifications | Cabinet size | 500*500 | 500*500 | 500*500 | 500*1000 |
| Cabinet pixel | 192*192 | 168*168 | 128*128 | 128*256 | |
| Density (dot/m2) | 147456 | 112896 | 65536 | 65536 | |
| Brightness(cd/m2) | 500-1000 | 500-1000 | 500-1000 | 500-1000 | |
| Max power consumption (W/piece) | 160W | 160W | 160W | 320W | |
| Avg power consumption (W/piece) | 50W | 50W | 50W | 100W | |
| Cabinet weight(KG) | 7.5KG | 7.5KG | 7.5KG | 13.6KG | |
| Cabinet material | Die-cast magnesium aluminum box | ||||
| IP grade | IP45 | IP45 | IP45 | IP45 | |
| Gray level | 16 bit | 16 bit | 16 bit | 16 bit | |
| Fresh rate | 3840HZ | 3840HZ | 3840HZ | 3840HZ | |
| Best viewing distance | 3M | 3M | 4M | 4M | |
| Power(V) | AC110-220V | ||||
| Working temperature | -20℃-50℃ | ||||
FAQ:
1. Training after order
After the order is placed, a processional training will be offered, including software use, operate safety, maintain equipment
2. Installation and debugging
Wecould send professionals to conduct on site installation and debugging in strict accordance with the requirements of the schemes and original manual.
3. Warranty
Warranty: 3 years warranty, lifetime maintenance
Equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance if any problem caused by quality itself. While you should take the cost of the freight to us. After 2 years, service is still available, but would charge for labor, material and freight cost that generates.
4. Maintenance
Maintenance principles: response in time, solve problems asap and ensure the use.
Maintenance period: In the maintenance period of the led display body, free of all maintenance charges
After maintenance period, only charge the material cost and labor cost.
