P6.67 960x960mm Advertising LED Billboard
P6.67 Outdoor Fixed LED Display Full Color LED Billboard For Commercial Advertising
Functin of LED Display:
1. High reliability. 24h/7day advertising all the time and all weather conditions.
2. Energy-saving technology,due to special driver ic and led and power supply
3. High brightness lamp beads, brightness can be automatically adjusted
4. TiSuper high brightness 6000nits makes led screen still be very clear under the sunshine.dy and beautiful , good heat dissipation.
5. High refresh rate makea good visual effect .
6. High Quality: CE, RoHs, FCC, UL, IP65, ISO9001 passed + 96 Hours serious testing time.
7. Long life span: over100,000hours, warranty at least 2 years.
8. You need = We design: Provide Personal- Customized led display offer.
|
Model |
P4 |
P5 |
P6 |
P8 |
P10 |
|
Pixel Pitch(mm) |
4 |
5 |
6.67 |
8 |
10 |
|
LED Chips |
SMD1921 |
SMD2525 |
SMD3535 |
SMD3535 |
SMD3535 |
|
Pixel density(dots/m2) |
62500 |
40000 |
22477 |
15625 |
10000 |
|
Driving Method |
1/10 scanning |
1/8 scanning |
1/6 scanning |
1/5 scanning |
1/2 scanning |
|
Module Size(mm) |
320*160 |
320*160 |
320*160 |
320*160 |
320*160 |
|
Module Resolution |
80*40 |
64*32 |
48*24 |
40*20 |
32*16 |
|
Cabinet Size( W*L mm) |
960*960 |
960*960 |
960*960 |
960*960 |
960*960 |
|
Cabinet Material |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
|
Cabinet Weight( Kg/m2 ) |
35 |
35 |
35 |
35 |
35 |
|
Max.Consumption(W/m2) |
800 |
800 |
800 |
800 |
800 |
|
Ave.Consumption(W/m2) |
350 |
350 |
350 |
350 |
350 |
|
Brightness( Nits ) |
≥5500 |
≥5000 |
≥5500 |
≥5800 |
≥6000 |
|
Viewing Angle (Vertical / Horizontal) |
120° / 120° |
120° / 120° |
120° / 120° |
120° / 120° |
120° / 120° |
|
Refresh Rate |
≥1920Hz |
≥1920Hz |
≥1920Hz |
≥1920Hz |
≥1920Hz |
|
IP Level |
IP65 |
IP65 |
IP65 |
IP65 |
IP65 |
FAQ:
Q1: What's the pixel pitch for Indoor LED Display Screen ?
A1: Outdoor P3.91mm
Q2: Where is it used for?
A2: Indoor rental use. Widely used for backdrop of staging event, rental business, liveshow, concert, etc.
Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Novastar controlling system.
Q4: What's the controlling system?
A4: Our standard controlling system for this model is Novastar. Also support other controlling system, like Linsn, etc.
Price Advantage:
We have the best competitive price at the market, also have the same even better quality
Quality advantage:
From material to finished product, from design to produce, we control all steps,that's the guarantee of the quality and reliability
Service advantage:
Better service at same situation, better cooperation at same service.
About Us:
Shenzhen Eliteled Electronics Co. Limited is a full range manufacturer and LED display solutions provider and its ancillary systems worldwide since 2009, headquartered in Shenzhen with a 6, 000m² production state of the art facility to cover international demands. We provide a one-stop shopping in the design, production, and distributions of LED displays and solutions for our customers domestically and globally.
Our products include ranges of indoor, outdoor, fixed, rental and creative LED Solutions for various applications including sports, advertisement, concerts, shopping malls, stadiums, exhibitions or any other indoor and outdoor events that comes to your imagination.
We keep the company culture ``Professional, Concentration, Focus`` aimed at LED. With the development of LED technology and the perfervid competition in the LED field.
