High Definition 320*160 Large Led Advertising Screens P5 LED Video Wall Weatherproof
Light Weight High Definition P5 Outdoor Full Color Led Display Boards , LED Video Wall
Mainly for outdoor advertising, information publishing, journalism and communication in some places, such as cultural square, traffic arteries, stations, terminals, information centers, entertainment venues, shopping, centers, commercial city and etc.
Key Specifictions:
1. High brightness SMD3535 and SMD2727 LED is used for outdoor LED display, keeps the display content visible even if facing the strong sunshine directly.
2. Weatherproof design, completely outdoor use.
3. High color uniformity and clear image can bring you a vivid audio visual effect.
4. Easy for assembling and connection with the connector added.
5. Optional of convex shaped,concave shaped and wave shaped screens
6. Standard cabinet achieves seamless and smooth assembling overall the display.
7. The cabinet can be operate in all-weather for its slim design and waterproofing that with a protection level of class IP65 in front and IP54 in back.
8. Easy installment and low maintenance cost
|
Model |
P4 |
P5 |
P6 |
P8 |
P10 |
|
Pixel Pitch(mm) |
4 |
5 |
6.67 |
8 |
10 |
|
LED Chips |
SMD1921 |
SMD2525 |
SMD3535 |
SMD3535 |
SMD3535 |
|
Pixel density(dots/m2) |
62500 |
40000 |
22477 |
15625 |
10000 |
|
Driving Method |
1/10 scanning |
1/8 scanning |
1/6 scanning |
1/5 scanning |
1/2 scanning |
|
Module Size(mm) |
320*160 |
320*160 |
320*160 |
320*160 |
320*160 |
|
Module Resolution |
80*40 |
64*32 |
48*24 |
40*20 |
32*16 |
|
Cabinet Size( W*L mm) |
960*960 |
960*960 |
960*960 |
960*960 |
960*960 |
|
Cabinet Material |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
|
Cabinet Weight( Kg/m2 ) |
35 |
35 |
35 |
35 |
35 |
|
Max.Consumption(W/m2) |
800 |
800 |
800 |
800 |
800 |
|
Ave.Consumption(W/m2) |
350 |
350 |
350 |
350 |
350 |
|
Brightness( Nits ) |
≥5500 |
≥5000 |
≥5500 |
≥5800 |
≥6000 |
|
Viewing Angle (Vertical / Horizontal) |
120° / 120° |
120° / 120° |
120° / 120° |
120° / 120° |
120° / 120° |
|
Refresh Rate |
≥1920Hz |
≥1920Hz |
≥1920Hz |
≥1920Hz |
≥1920Hz |
|
IP Level |
IP65 |
IP65 |
IP65 |
IP65 |
IP65 |
FAQ:
Q1: Can the LED display screen work at corrosive gas environment?
A1: Please do not install the display in corrosive gas environment containing acid or base components, such as chemical warehouse.
Q2: Can the LED display screen work at electromagnetic radiation environment?
A2: Please do not install display when electromagnetic radiation and radio frequency radiation environment is over field strength 5V/m.
Q3: Can the LED display screen work when lightning?
A3: If necessary, users have to install surge switches in the distribution box and ground fault protection to avoid lightning strikes. Do not use the display in strong lightning and other severe weather.
Q4: How long can the LED display screen display?
A4: LED display at least rest 2 hours a day. Normally turn on the screen at least twice a week or more (Especially in the rainy season it is necessary to turn on the display every day). And it maintains more than 2 hours every time.
Our Service and Mission:
EliteLED has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
Why Choose Us?
1. Your inquiries will be replied within 12 hours!
2. Our sellers speak English and Spanish. Engineering men speak English.
3. Make considerate solutions based on your situation and requests.
4. 365 days after service support.
5. All life guarantee and free charge within two years.
6. Protection of your sales area, ideas of design and all your private information.
7. Top Quality + Reasonable Price + Responsible After Service = Successful & Win
