P7.8 Large Outdoor Advertising Screen 1000x1000mm Waterproof Led Display
Outdoor P7.8 Energy Saveing Led Display Commercial Advertising Board
Specifictions:
1. Front access, slim aluminum cabinet, easy and fast to install and maintenance.
2. 2.8V&3.8V energy saving design, no need air-conditioner, environmental and save cost.
3. Support 90 degree installation, seamless splicing at the corner.
4. Totally warterproof of front and back IP67 and IP65.
5. Competitive price, you are welcome to contact us for a free project evaluation.
| Model No. | P10.41 | P7.8 | P6.25 | P5.2 | P4.8 | P3.9 |
| Pixel pitch | 10.4mm | 7.82mm | 6.25mm | 5.2mm | 4.81mm | 3.91mm |
| Pixel density (dots/m2) |
9246 | 16352 | 25600 | 36982 | 43264 | 65536 |
| LED encapsulation | SMD3535 | SMD2727 | SMD2727 | SMD2727 | SMD1921 | SMD1921 |
| Scan rate | 1/2 scan | 1/4 scan | 1/5 scan | 1/6 scan | 1/7 scan | 1/8 scan |
| Module size | 500 x 250 mm | |||||
| Module Resolution | 48 x 24 | 64 x 32 | 80 x 40 | 96 x 48 | 104 x 52 | 128 x 64 |
| Cabinet size | 1000 x 1000 x 73mm (Optional) | |||||
| Cabinet Resolution | 96 x 96 | 128 x 128 | 160 x 160 | 192 x 192 | 208 x 208 | 256 x 256 |
| Weight per Cabinet | 24.5 kg | |||||
| Brightness | ≥6500/ 10000nits |
≥6000/ 10000nits |
≥6000/ 10000nits |
≥5500/ 10000nits |
≥5000/ 10000nits |
≥5000/ 10000nits |
| Max.power consumption | 500W | 500W | 500W | 550W | 800W | 800W |
| Ave.power consumption | 175W | 175W | 175W | 185W | 270W | 270W |
| Energy Saving design | 2.8V & 3.8V Low voltage | 4.6V / 5V voltage | ||||
| Protection Degree | Front IP67/Rear IP65 | |||||
| Service | Front & Rear Dual service | |||||
| Power Supply | AC120 /240V (50Hz) (optional) | |||||
| Refresh Rate | ≥ 1920Hz(3840Hz Optional) | |||||
About Us:
EliteLED has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
FAQ:
1. About how to install it:
The good thing is, in many countries and regions, there are companies that will do the work for you.
If you don't know much about this industry, we can recommend our partners to help you install your outdoor LED display.
Just hit us up.
2. About how to use and operate:
We will provide online remote technical support, which can teach you how to use the LED display.
If you don't like going that route, we have very clear video tutorials as well that will guide you on how to use and operate your LED display screens.
Third, once you become our customer, you can actually visit our factory and have our guys teach you.
Lastly, if you want to work in this industry for a long time, you can become one of our dealers. We will send our technical staff to your country and train your guys on site every two year.
