120 Micron Weather Resistance 0.12mm PET Laminated Film
120 Micron Weather Resistance White Color Anti Corrosion Film
Description:
It is specially designed for waterproofing industry, which shall substitute conventional
exposed waterproofing material including the film for waterproofing membrane.
It also has cost effectiveness, and lasts over 25years of weather resistance.
Structure:
| It is laminated film, fluorine film laminated with PET film. |
| Inner side, it is PET film; |
| Outer side is fluorine film (Aging or Weather resistance). |
Advantages:
| 1. Excellent properties of anti-aging |
| 2. UV resistance |
| 3. Weather resistance |
| 4. Chemical corrosion resistance |
| 5. Resistance to high temperature,heat,humidity and extreme cold |
| 6. Reflectivity of over 85% |
| 7. High strength, tear resistance |
Application:
| It is used as the surface material: |
| 1. For waterproofing membranes; |
| 2. For weather resistance tapes. |
Weather Resistance Tape Application:
Waterproof Membranes Application:
Parameter:
| Detection Item | Detection Method | Detection Value | Remark | |
| Thickness | UF509 | GB/T6672-2001 | 0.128mm | / |
| Width | GB/T6673-2001 | / | According to customer needs | |
| Max force | UF509 | GB/T 328.9-2007 | MD:324N | Rectangular spline, spline width 25mm, stretching rate: 100mm / min, fixture gauge distance: 100mm |
| TD:348N | ||||
| Elongation at Break | UF509 | MD:406% | ||
| TD:260% | ||||
| Tensile Strength | UF509 | GB/T 529-2008 | MD:47N | Stretching speed:250mm/min |
| TD:43N | ||||
| Surface Tension | GB/T14216 | ≧42dyn/cm | Dyne Pen Test | |
| Dimensional change rate | UF509 | GB/T 35467-2017 | MD:0.96% | 90℃&24h |
| TD:0.77% | ||||
| Water vapor transmission rate | GB/T 21529 | ≦70 g/m2.24h (20um) | 38℃+100%RH | |
| Electrolytic sensor method | ||||
| Flammability grade | UL94 | VTM-0 | White weathering film | |
| Aging test | PCT96 | / | Yellowing index △b≤2.0, | Temperature 121 ℃, humidity 100%, air pressure 2atm, time 48h |
| UV300KWh | IEC61215 | The temperature of the sample is 60 ± 5 ℃, and the total exposure is 120KWh • m2, of which UVB accounts for 3% -10%. | ||
| DH2000h | IEC61215 | Temperature 85 ℃, humidity 85% R.H., 2000h | ||
| TC400 | IEC61215 | Temperature －40 ℃ ～ 85 ℃, 6h / cycle, 400cycle | ||
FAQ:
|
1).Can you offer free samples? Yes, we provide free samples, but we usually don't pay for freights.
2).Can you support customization? Sure, OEM&ODM are available.
3).Are you factory or trading company? We are manufacturer located in Taicang, we also have new plant in Chenzhou Hunan, welcome to visit us anytime.
4).What's your payment terms? Usually we prefer T/T, 30% deposit and 70% balance before shipmen. Anyway, T/T, L/C, Western Union, Money Gram, are acceptable. |
