Deligreen CATL 3.2V 310Ah Lithium Iron Phosphate Cell with 3000 Cycle Life for Solar Forklift
Deligreen CATL 310Ah 300Ah 48V Lithium Iron Phosphate Cell 3.2V LiFePO4 Battery for Solar Forklift applications.
DIY your battery pack - what type of lithium battery are you going to choose? The choice depends on the cathode material, with lithium-ion batteries divided into LCO, LMO, LNO, LFP, NCA, and NCM types.
| Cathode Material | Chemical Composition | Nominal Voltage | Energy Density | Cycle Life | Cost | Safety |
|---|---|---|---|---|---|---|
| LCO | LiCoO2 | 3.7V | Medium | Low | High | Low |
| LMO | Li2Mn2O4 | 3.6V | Low | Medium | Low | Medium |
| LNO | LiNiO2 | 3.6V | High | Low | High | Low |
| LFP | LiFePO4 | 3.2V | Medium | High | Low | High |
| NCA | LiNixCoyAl(1-x-y)O2 | 3.6V | High | Medium | Medium | Low |
| NCM | LiNixCoyMn(1-x-y)O2 | 3.6V | High | High | Medium | Low |
Choose the optimum battery for your application based on your specific requirements.
| Normal Capacity | 310Ah |
| Normal Voltage | 3.2V |
| Standard Charging Voltage | 3.65V |
| Internal Resistance | ≤0.3Ω |
| Standard Charge Method | 0.5C constant current charge to 3.65V for cell |
| Standard Discharge Current | 0.5C |
| Max Discharge Current (Continuous) | 2C for 60S, 1C for continuous |
| Weight | 5.3±0.1kg |
| Cell Dimensions | 173.8*71.5*207.45±0.5mm |
| Cycle Life | 3500 times |
| Internal Impedance | ≤0.7mΩ |
3.2V LiFePO4 310AH large capacity cell with aluminum housing.
| ITEM | CATL 60AH | CATL 75AH | CATL 100AH | CATL 240AH | CATL 271AH | CATL 310AH |
|---|---|---|---|---|---|---|
| Nominal Capacity | 60AH | 75AH | 100AH | 240AH | 271AH | 310AH |
| Nominal Voltage | 3.2V | 3.2V | 3.2V | 3.2V | 3.2V | 3.2V |
| Discharge Cut-off Voltage | 2.5V | 2.5V | 2.8V | 2.5V | 2.5V | 2.5V |
| Charge Current | 12A (0.2CA to 3.65V) | 15A (0.2CA to 3.65V) | 20A | 48A | 54.2A | 62A 0.2C |
| Charge Voltage | 3.65V | 3.65V | 3.65V | 3.65V | 3.65V | 3.65V |
| Max Charge Voltage | 3.7V | 3.7V | 3.7V | 3.7V | 3.7V | 3.7V |
| Fast Charge Current | 60A | 75A | 100A | 240A | 271A | 310A |
| Max Continuous Charge Current | 60A | 75A | 100A | 240A | 271A | 310A |
| Max Continuous Discharge Current | 90A | 112.5A | 100A | 240A | 271A | 310A |
| Weight | 1.69KG | 2.12KG | 2.3KG | 5.1KG | 5.33KG | 6KG |
| Size | 150.5*174.5*32.5mm | 128*174*48mm | 168*200*34.5mm | 200*174*75mm | 200*174*75mm | 72*174*204mm |
| Internal Impedance | ≤0.7mΩ | ≤0.7mΩ | ≤0.7mΩ | ≤0.5mΩ | ≤0.3mΩ | ≤0.5mΩ |
Important Note: CATL 310Ah cells are required by our cooperated partner, and the QR code is erased. We promise brand new cells, not recycled. True capacity is around 300Ah. If you mind this, please do not place an order.
Comes with fixed stud, including busbars and screws for connection:
- Busbars size: 90*20*2mm
- Screw size: M6
We test all battery voltage and internal resistance before shipping.
Screw-connected prismatic battery cells can be easily mounted/connected with busbars/screws for DIY assembly.
| Storage Condition | Charge Retention Rate | Capacity Recovery Rate |
|---|---|---|
| Temp | SOC | Time | ||
| 55℃ | 100% | 7 days | ≥92% | ≥95% |
| 25℃ | 100% | 28 days | ≥92% | ≥95% |
| 45℃ | 50% | 28 days | - | ≥90% |
- Exercise caution when working with all electrical equipment
- Wear safety glasses, gloves etc. when appropriate
- Sparks & flashes can damage your eyes
- Ensure cells are within operating temperature range prior to use
- Do not use if cells are punctured, damaged or leaking
- Provide adequate protection to cells during assembly & use thereafter
- Dispose of properly to recycling or similar facility
- Do not submerge in water
- Do not allow to come in contact with direct heat, extreme temperatures or fire
- Prevent harsh impacts or extreme vibrations which can cause immediate or cumulative damage
Deep cycle capability with more than 2000 times life span. Longer life than lead acid batteries.
This lithium battery is available for many applications including golf carts, RVs, solar storage systems, E-motorcycles, home energy storage systems, powerwalls, and more.
Shipment to USA: By sea + Express (DDP, Tax free)
- ETD: 5-8 days
- ETA: 25-35 days after sailing
- Tracking will be updated after pick up by local express
- Usually takes around 15-25 days after sailing
Shipment to EU: By railway + Express (DDP, Tax free) - Except Switzerland, Romania
- ETD: 5-8 days
- ETA: 30-45 working days after shipping
- Tracking will be updated after pick up by local express
- Usually takes around 25-40 working days after shipping
For other remote areas not listed, please provide shipping address and zip code to us for checking.
