0.5T 820-1768mm Transmission Floor Jack Adjustable Platform + Chains For Car / SUV Repair
Price:
Negotiable
MOQ:
50pcs
Delivery Time:
30-45DAYS
Brand:
YEEDA
Product Description
YD05-002A 0.5T Compact Transmission Jack
Professional tool designed for disassembling and assembling gearboxes of family cars (RWD/FWD) with GVM < 2000kg. Features adjustable platform and load chains for precise adaptation, safe fixation, and flexible lifting.
Product Specifications
| Parameter Category | Specific Value |
|---|---|
| Product Name | YD05-002A 0.5T Compact Transmission Jack |
| Model No. | YD05-002-A |
| Safe Working Capacity | For RWD/FWD vehicles, GVM < 2000kg |
| Rated Capacity | 0.5T (500 kg) |
| Lifting Height | Minimum: 820 mm Maximum: 1768 mm |
| Lifting Platform | Size: 250 × 362 mm, adjustable |
| Weight | Nett: 52 kg Gross: 59 kg |
| Carton Size | 490 × 310 × 770 mm |
| Core Configuration | Steel frame, adjustable platform, 2 load chains, 4 swivel castors with brakes, hydraulic system, anti-slip pad |
Key Features
- 500kg Load-Bearing: Q235 steel frame with 8mm main rods, 0.2mm max deformation under load, phosphating + electrostatic painting for durability.
- 820-1768mm Lifting Range: Adapts to both low-chassis sedans and high-chassis SUVs with ±50mm platform adjustment.
- Load Chains + Anti-Slip Pad: 2 high-strength chains (≥300kg each) and 3mm rubber pad (friction ≥0.9) for secure fixation.
- 4 Swivel Castors: 70mm wheels (2 with brakes), ≤55dB noise, compact storage (490×310×770mm).
Application Scenarios
- Family car gearbox replacement in auto repair shops (e.g., BMW 3 Series, Toyota Reiz)
- FWD SUV gearbox maintenance (e.g., Haval H6, Changan CS75)
- Home maintenance by individual auto enthusiasts (e.g., Honda Civic, Nissan Sylphy)
- Transmission auxiliary cleaning in auto beauty shops (e.g., Mercedes-Benz C-Class, Audi A4L)
Frequently Asked Questions
Q1: Can it adapt to the gearbox of a FWD SUV with GVM=1900kg?
A1: Yes. 1900kg is within the safe adaptation range (GVM < 2000kg). The transmission weight (300-400kg) is below the 500kg rated capacity. Adjust platform and use chains for secure operation.
Q2: How does the adjustable platform adapt to different oil pan shapes?
A2: Loosen adjustment knobs to move platform horizontally/vertically, aligning support points with oil pan load-bearing parts. Fine-tune height (±20mm) for protrusions.
