2T Low Jack: 22-82cm, Wide Base + Handle Op for SUV/Truck/Engineering Machinery Repair
Professional tool designed for convenient and stable disassembly/assembly of heavy-duty power components in ultra-low chassis vehicles. Features 22-82cm lifting range, wide base for stability, and handle operation for ease of use.
| Parameter Category | Specific Value |
|---|---|
| Product Name | YD05-015 2T Low Transmission Jack |
| Model No. | YD05-015 |
| Capacity | 4400 LBS (2000 KGS) |
| Main Design | Compact design with extra wide base for stability |
| Lifting Height | Min: 8.67" (22 cm) Max: 32.28" (82 cm) |
| Operation Method | Handle operator (labor-saving) |
| Weight | Gross: 222 LBS (101 KGS) Net: 200 LBS (91 KGS) |
- 2000kg Heavy Load Capacity: Alloy steel frame with 12mm main beam thickness, tested for durability
- Ultra-Low 22cm Profile: Accesses tight spaces under low chassis vehicles
- Extra Wide Base: 113×54cm footprint for superior stability
- Handle Operation: Labor-saving design requiring only 16-20kg pressure
- Modular Assembly: No professional tools required, assembles in 25 minutes
Q355 low-carbon alloy steel frame with 510MPa tensile strength. Epoxy resin coating resists oil, scratches, and corrosion with 12+ year lifespan.
54cm width reduces space occupancy by 30% compared to standard jacks, fitting 90% of ultra-low chassis maintenance scenarios.
0.61㎡ base area with 4 anti-slip rubber pads (friction coefficient ≥0.98) and overturning coefficient ≤0.18 for maximum safety.
22cm height accesses Porsche 911 Turbo, Lamborghini Huracan chassis. Reduces maintenance time from 5 to 3 hours.
2000kg capacity handles Foton Omarco S5, JMC Kairui N800 differentials (≈1500kg).
Operates without external power on small road rollers and micro excavators at construction sites.
