Heavy-Duty work 10 Ton battery forklift electric CPCD100 China made

Price Negotiable
Price: USD50000/set
MOQ: 1 set
Delivery Time: 30 working days
Brand: XDEM
Product Description
Product Description

Electric Warehouse Forklift detail:
As a professional manufacturer of forklift, we also can offer you customized service,
The following items are optional:
Container mast, for example, 2-stage full free mast of 3m, 3-stage full free mast of 4.5m/ 4.8m/ 5m/6m Side shifter, fork
positioner, longer forks, fork extension
For the details of customized configurations and options, please contact with us.
VMAX professional service will be impressed on you



.



Heavy-Duty work 10 Ton battery forklift electric CPCD100 China made

As one of the most famous material handling manufactures in China,we specialize in this field for over 10 years, with the strength of diesel forklift , Electric forklift , LPG forklift , reach truck, pullet truck and stacker.
Now our dealers has been wide spread in many countries like Russia, Australia,Turkey, Brazil, Mexico etc. Also We company had obtained the following certificates in this industry with the development of over 10 years:
1. CE certificate
2. ISO 9001:2008 Standard approved
3. BV&SGS Factory Audit Pass Report
4. Alibaba golden supplier for 7 years
Besides, we are always trying to be innovative and have won several patent certificate on forklift in China.
Currently the factory's capacity per year is 5000 sets(including all sorts of forklift) and averagely the leading production time is 20-30 days. While standing to expand our brand, we also gladly accept OEM based model in which you can pick Japan Engine/Curtis Controller/different forklift attachment and any you like.

We do more than just selling product, but also provide material handling solution for customer. We're sure that it can satisfy your demand if needed.
Details Images



Product Paramenters
10 ton electric forklift specification
Manufacturer


Model

CPD100
Power type

Lithium battery
Rated capacity
kg
10000
Load center
mm
600
Lifting height
mm
3000
Mast tilt angle
Deg
6°/12°
Length with fork
mm
4260
Overall width
mm
2240
Height of mast (closed)
mm
2840
Height of mast (extended)
mm
4320
Overhead guard height
mm
2560
Front overhang
mm
720
Min. ground clearance
mm
235
Min. Turning radius
mm
4080
Min. Intersecting aisle
mm
3540
Max.Drive speeds(with/without load)
km/h
14/16
Lifting speeds (with load)
mm/s
280/300
Lowering speeds(with /without full load)
%
15/20
Tire,front

9.00-20-16PR
Tire,back

9.00-20-16PR
Track width, front / rear
mm
1600/1722
wheelbase
mm
2800
Weight
kg
13900
Battery (voltage / capacity)
V/Ah
80/1080
Traveling motor power(S2-60min)
kW
30
Lifting motor power(S3-15%)
kW
2X26
Controller

Inmotion
Control mode

Full AC motor
Lifting motor power
kw
12
Level voltage/Capacitance
V/Ah
'48/490
Drive System

DC/AC
Electrical control system

Inmotion/Curtis from America
