Socket Type 2 32A 240V 7kw Electric Car Charger
Type 2 Socket 7KW 32A 240V Module 3 AC EV Charger Station With MID Certified
Feature:
Easy to install and maintain
Universal charging socket
Adjustable charging rating: 6A, 13A, 16A and 32 A
Power rating: up to 7.2kW (32A)
Built-in 6mA DC sensitive protective device
Built-in LED Charging status indicator
IP 54 waterproof & UV stabilised
Corrosion resistant & fire retardant
Impact resistant design
Large LCD to display all the car's data on the charging station during charging. Can see the state of charge, including current, voltage and temperature. The screws are fit into the box so don't have to worry about the screen falling.
EV Charger Station Specifications:
| Model Name | EVC10-07C1S | EVC10-07C1C | EVC10-22C1S | EVC10-22C1C | |
| Input Rating | 230±10%Vac (One Phase) | 400±10%Vac (Three Phase) | |||
| Frequency | 50Hz | ||||
| Input Current | 32A | ||||
| Output Current | 32A | ||||
| User Authentication | RFID (ISO 14443) | ||||
| External | LAN (optional) + 4G (optional) or Wi-Fi (optional) | ||||
| Internal | OCPP 1.6 JSON (OCPP 2.0 compatible) | ||||
| Operating Temperature | -22˚F~122˚F(-30˚C~50˚C) | ||||
| Humidity | Max. 95% RH | ||||
| Altitude | ≦ 2000m | ||||
| IP Level | IP 54 | IP65 for box | IP 54 | IP65 for box | |
| Dimension(WxDxH) | 350x250x175mm (13.8″x9.8″x6.9″) | 350x250x130mm (13.8″x9.8″x5.1″) | 350x250x175mm (13.8″x9.8″x6.9″) | 350x250x130mm (13.8″x9.8″x5.1″) | |
| Charging Outlet | One Socket | 5M Cable | One Socket | 5M Cable | |
| RCD | RCD TYPE B | ||||
| Charging Interface | Type 2 Plug | ||||
| Multiple Protection |
Over current, Under voltage, Over voltage, Residual current, Surge protection, Short circuit, Over temperature, Ground fault, Current leakage protection |
||||
