China 6.5 inch Professional speaker loudspeaker coaxial speaker 6.5
China 6.5 inch Professional speaker loudspeaker coaxial speaker 6.5
China 6.5 inch Professional speaker loudspeaker coaxial speaker 6.5
China 6.5 inch Professional speaker loudspeaker coaxial speaker 6.5

6.5 inch Professional speaker loudspeaker coaxial speaker 6.5"

Price Negotiable
Price: $15.00 - $55.00 / Piece
MOQ: 2 Piece/Pieces
Delivery Time: Negotiable
Brand: HYYX
Product Description
Product Description


Features :





- 300W continuous program power capacity
- 94dB sensitivity
- 80hz-18khz Frequency response
- Single magnet design
- Titanium / Polyester diaphragm for HF driver



- 25mm(1") HF throat size
- 2" LF VC + 1.7" HF VC
- Replacement diaphragm for HF , Titanium or Polyester

Speccification :

Specification
Nominal diameter
170/6.5
mm/inch
Nominal impedance
8
ohm
Min impedance LF
5.2
ohm
Min impedance HF
6
ohm
Frequency response
80-18k
Hz
Dispersion angle
70
°
Magnet size
145x25
mm
Magnet material
Ferrite

Specification LF
Sensitivity (1w/1m)
94
dB
Nominal power handling
150
Watts
Continuous power handling
300
Watts
Voice coil diameter
50/2 "
mm/ inch
Winding material
Copper

Cone material
Paper

Surround material
Cloth

Specification HF
Throat size
25/1
mm/inch
Sensitivity (1w/1m)
106
dB
Nominal power handling
50
Watts
Continuous power handling
100
Watts
Voice coil diameter
44/1.7
mm/inch
Diaphragm
Titanium / Polyester

T/S Parameter
Fs
82.5
Hz
Re
5.2
Ω
Qes
0.78

Qts
0.74

Qms
15.24

Vas
8.8
L
Rms
0.4
kg/s
Cms
0.31
mm/N
Mms
12.1
gr
BI
6.5
N/A
Rp
70.0
Ω
Lp
13.3
mH
Cp
508.7
uF
Le
0.5
mH
Xmax
6.5
mm
Mounting information
Overall diameter (Diagonal)
185/7.28
mm/inch
Bolt Circle diameter
170/6.7
mm/inch
Baffle Cutout diameter
147/5.78
mm/inch
Depth
114/4.48
mm/inch
Flange thickness
9/0.35
mm/inch
Shipping information
Net weight
2.8
KG
Shipping weight
3.3
KG
Shipping box
190x190x145
mm
