Paper Cone DC 12V 1500W 12 Inch 90dB Car Audio Subwoofer
1. High end Super SPL car subwoofer with good sound quality
2. Aluminium frame, triple magnet, 230 oz , dual 2/4ohm 3 " high temperature copper voice coil
3. Long throwing , dual voice coil, high power , high dynamic
4. Show sink, strong, clean and flexible low-frequency performance
5. Ziced top-plate and washer, nice appearance
6. Reinforced & coated paper cone , double spider with double flat tinels leads
|
Model |
HYW-1275-053A |
|
Item |
12" Subwoofer with dual 2ohm/4ohm voice coil |
|
Size |
12 inch |
|
Voice coil |
75mm/3" high-temp copper VC |
|
RMS |
1500WRMS |
|
MAX power handing |
3000W |
|
SPL |
90dB |
|
Cone |
Pressed paper |
|
Impedane |
Dual 2 ohm / Dual 4ohm |
|
Frequency response |
35-1.5khz |
|
Magnet |
Triple 190mm/ 230 oz |
|
Diameter |
12" / 300mm |
|
Mounting diameter |
297mm |
|
Mounting depth |
170.5mm |
|
XMAX |
30mm |
|
Qts |
0.33 |
|
Vas |
30.1 liter |
|
Qes |
0.35 |
|
Net weight |
13.7KG |
|
Box recommendation vented |
45 Liter / 1.59 cu.ft |
|
Box recommendation sealed |
60 Liter / 2.12 cu.ft. |
