450W 15 Inch Woofer Speaker 98dB PA Sound Equipment
Top quality 15 inch woofer speaker for pro audio midbss speaker driver made in China
Features :
- Professional 15 inch woofer speakers with good bass sound quality
- 900W continuous program power capacity, 450W RMS power handling
|
Specification
|
|
|
||
|
Nominal diameter
|
380/15
|
mm/inch
|
||
|
Nominal impedance
|
8
|
ohm
|
||
|
Min impedance LF
|
5.2
|
ohm
|
||
|
Frequency response
|
30-3k
|
Hz
|
||
|
Magnet size
|
190x20
|
mm
|
||
|
Magnet material
|
Ferrite
|
|
||
|
Sensitivity (1w/1m)
|
98
|
dB
|
||
|
Nominal power handling
|
450
|
Watts
|
||
|
Continuous power handling
|
900
|
Watts
|
||
|
Voice coil diameter
|
75/3
|
mm/ inch
|
||
|
Winding material
|
CCAW
|
|
||
|
Cone material
|
Paper
|
|
||
|
Surround material
|
Cloth
|
|
||
|
T/S Parameter
|
|
|
||
|
Fs
|
40.1
|
Hz
|
||
|
Re
|
5.2
|
Ω
|
||
|
Qes
|
0.76
|
|
||
|
Qts
|
0.71
|
|
||
|
Qms
|
12.39
|
|
||
|
Vas
|
162.9
|
L
|
||
|
Rms
|
2.1
|
kg/s
|
||
|
Cms
|
0.15
|
mm/N
|
||
|
Mms
|
105.1
|
gr
|
||
|
BI
|
13.5
|
N/A
|
||
|
Rp
|
49.6
|
Ω
|
||
|
Lp
|
27.1
|
mH
|
||
|
Cp
|
1185.7
|
uF
|
||
|
Le
|
0.8
|
mH
|
||
|
Xmax (one-way)
|
4
|
mm
|
||
|
Mounting information
|
|
|
||
|
Overall diameter
|
393/15.47
|
mm/inch
|
||
|
Bolt Circle diameter
|
374/14.72
|
mm/inch
|
||
|
Baffle Cutout diameter
|
355/13.98
|
mm/inch
|
||
|
Total Depth
|
159/6.26
|
mm/inch
|
||
|
Mounting depth
|
145/5.71
|
|
||
|
Flange thickness
|
14/0.55
|
mm/inch
|
||
|
Shipping information
|
|
|
||
|
Net weight
|
8
|
KG
|
||
|
Shipping weight
|
9
|
KG
|
||
|
Shipping box
|
430x430x190
|
mm
|
||
Company Profile
Since our establishment in 2009, we have been committed to manufacturing high-quality audio products, including professional audio speakers, car audio speakers, speakers with cabinets and power amplifiers. Since then, Huiyin Audio Co., Ltd. has had a complete high-quality supply chain, an excellent management team, and the ability to provide our customers with good service and high-quality products at a good price! Instead, the company introduced a series of advanced equipment such as automated production lines, high-efficiency magnetizers, impact testing machines, and temperature testing machines. To maximize, we obtained CE certification in 2012. The enterprise will be gradually developed in 2017.
We are willing to customize the speakers and amplifiers required by customers to suit their market. OEM and ODM orders are welcome.
Committed to strict quality control and thoughtful customer service, our experienced staff are always available to discuss your requirements and ensure complete customer satisfaction. When we cooperate with well-known Chinese brands, our products are also exported to customers in North America, South America, Europe, Asia, Africa and Africa and Oceania and other countries and regions. Whether it is selecting the current product from our catalog or seeking the help of an engineer to manufacture other ideal speaker models, please contact our customer service center or send an email to us. We want to establish a long-term business relationship with you.


1.Q: Are you a factory ?
A: Yes, We are professional manufacturer who focus on quality speakers so that we could build long time business with customers.
2.Q: What's your products range?
A: Pro audio speaker, car audio speaker and home audio speaker .
3.Q: Can I get some samples?
A: Yes, we could provide samples and ship samples by DHL, EMS, FedEx or by sea .
4.Q: What's the payment method ?
A: T/T , Western union and PayPal.
5.Q: Can you print our logo on the speaker and packing?
A: Yes , we would like to do it for your OEM orders .
6.Q: Could you build speakers based on customer's design ?
A: Yes , customized order is welcome .
