DN100 Casting Forged Steel Carbon Stainless Steel Flanged End Handwheel Floating Ball Valve
Standard Casting Forged Steel Carbon Stainless Steel Flanged End Handwheel Floating Ball Valve
Stainless Steel Ball Valve Features
- Investment casting body and cap
- Working pressure 1/4' -2'' 1000PSI , 2 1/2''-4'' 800 PSI
- Adjustable stem packing
- Pure teflon seals and seats
- Temperature range : -60 to 450o F
- Blow-out proof stem
- 100% leakage tested at 100PSI air under water
- Locking device (optional)
Ball Valve Properties
| Testing pressure | Nominal pressure(Mpa) | ||||
| PN | 1.6 | 2.5 | 4.0 | CL150 | JIS10K |
| Strength test | 2.4 | 3.8 | 6.0 | 3.2 | 2.4 |
| Sealing test | 1.8 | 2.8 | 4.4 | 2.2 | 1.5 |
| Air test | 0.5~0.7 | ||||
| Working temperature | PTFE≤150°C,PTL≤300°C4. | ||||
Product Show
Workshop&Certification
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.But we have our own foreign trade team!
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: General is 100%TT deposit, or 30% advance payment, balance paid before shipment.
Q: Could you specially design and produce for clients?
A: Yes,Of course! We have experienced engineers, we can produce according to your requirements or drawings!
