99% Wedge Wire Filter
Stainless Steel 304 Customized Wedge Wire Strainer For Water Well
Materials:
Due to the water well is under ground,maybe tens meters,It's hard to change and repair.So it must be a long work time to reduce the cost for repairing and changing.Also,it needs to be untirust.Therfore, the wedge wire strainer we supply for you is suitable for your work place.It is stainless steel, for rust protection.The structure of the strainer is very high rigidity for a long work time and firm.
| Wedge wire | width(mm):1.50 1.80 2.30 3.00 3.30 3.70 Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00 |
| Support rod | Width(mm): 2.30 3.00 3.30 3.70 Height(mm): 2.70 3.60 4.70 5.60 6.30 Round: From 2.50mm to 6.0mm |
| Slot size | 0.10 0.15 0.20 0.25 0.30.....6.00mm also achieved upon request. |
| Material | Stainless steel(304,316,316L etc.) |
| Length | up to 6m |
| Diameter | from 26mm to 1200mm |
| End connection | Plain beveled ends, flanged or threaded couplings |
Characteristic:
1. A constant port opening which significantly improves the available open up area, therefore providing better access to the drinking water having area
2. A V-formed user profile wire which prevents blocking and ensures an uninterrupted circulation.
3. A standard and productive well development due to ongoing port starting.
4. Ladder-like wire welded screens have got a strong construction and high wide open region, along with precise slot sizing.
5. Ladder-like wire welded display screens possess the features of straightforward backwashing, go very far, protection and reliability in addition to reduced thorough price.
As the Ladder -like wire structure and the V-shaped and circular cross section,there will be more fulient.
Advantage
Maximazing fluid charges :
When contemplating displays of identical span, size and slot dimension, movement prices through V-formed well screens can be Three occasions higher than bridge-port screens Nine periods beyond slotted housing
Low blocking slot :
Ongoing-port well display screens have V-formed openings that narrowest with the exterior face and broaden inwardly, hence, extra-large contaminants are retained outside of the display and particles passing with the thin outdoors launching can enter the display.
Reduction in working price :
Using a Continous-port well display screen, savings can be achieved in pumping fees. Lower through-slot velocities imply that stress falls are
minimized, as a result :Drawdowns are lessened, Less vitality is needed for working, Movement prices are improved, A lot less yellow sand within the water reduces wear on the pumps.
The details of profiles:
Application:
Packages:
The delivery
