V Shaped Opening Wedge Wire Strainer Sieve Tube Resist Compression
Stainless Steel 304 And 316 High Rigidity Wedge Wire Strainer For Water/Solid Or Air/Solid Separation
The Wedge wire strainer is known as wedge wire screen,wedge wire filter,etc.It includes the wedge wire and support rods,The wedge wire and the support rods are welded together.The structure of the strainer is four kind:
1.Wedge wire is one piece and ouside,rods are some and inside
2.Wedge wire is one piece and inside,rods are some and outside.
3.Wedge wires are some and outside,the rod is one piece an inside.
4Wedge wires are some and inside,the rod is one piece an outside.
The rod has two kind profiles:Wedge and circular.
| SIZE (INCH) |
O.D (MM) |
SLOT (INCH) |
LENGTH (M) |
COLLAPSE STRENGTH (PSI) |
TENSILE WEIGHT (TON) |
WRAP(thick*deep) (MM) |
RODS (MM) |
| 4 | 117 | 0.040 | 3 | 395 | 6 | 2.2*3.0 | 3.8MM/22 |
| 4 | 114.3 | 0.040 | 3 | 395 | 6 | 2.3*3.0 | 3.8MM/22 |
| 6 | 168.3 | 0.040 | 3 | 252 | 8 | 2.3*3.5 | 3.8MM/32 |
| 8 | 219.1 | 0.010 | 3 | 399 | 10.5 | 3.0*5.0 | 3.8MM/48 |
| 8 | 219.1 | 0.020 | 3 | 370 | 10.5 | 3.0*5.0 | 3.8MM/48 |
| 8 | 219.1 | 0.040 | 3 | 323 | 10.5 | 3.0*5.0 | 3.8MM/48 |
| 10 | 273.1 | 0.010 | 3 | 206 | 11 | 3.0*5.0 | 3.8MM/50 |
| 10 | 273.1 | 0.020 | 3 | 191 | 11 | 3.0*5.0 | 3.8MM/50 |
| 10 | 273.1 | 0.040 | 3 | 167 | 11 | 3.0*5.0 | 3.8MM/50 |
The Benifits of V-shape Wedge Wire Filter
1, good filtration performance, 2-200μm particle size can play a uniform surface filtration performance;
2, corrosion resistance, heat resistance, pressure resistance, wear resistance;
3, stainless steel filter element uniform pores, filtration accuracy;
4, stainless steel filter unit area of large flow;
5, stainless steel filter for low temperature, high temperature environment; After cleaning, it can be reused without replacement
The Function:
- The application of wedge-shaped wire on the filter element makes the v-shaped opening formed between the gaps of the screen tube. Because of the innate advantages of the device can be operated than other forms of filtration products, water filtration is not only smooth, but also in terms of the work efficiency of the wedge wire filter pipe flow is bridge filter pipe 3 times, is slit filter pipe 9 times!
- Structural advantages of wrapped wire tubes. According to the actual needs of the design of the longitudinal support rod arrangement, and the screen tube continuity gap form, so that the product has more high compression resistance. T - shaped winding wire and all longitudinal support rod are connected by electric welding combination, strong, longer working life cycle, low overall cost.
- Filter pipe gap range is large. Any screen gap size between 0.02mm and 60mm can be made according to actual requirements to meet different application conditions.
The Wedge wire filter is useful for your tasks in any of the following areas:
Ming, coal, oil, fertilizer, chemical, grain, salt, environmental protection and so on. Screening of liquid and powder
Wires and Rods Information
The most common wire
The most common support rod
The Package:Wooden box
The delivery
Please Meet us on The http://www.wedgefilter.com
