Purple Horn 12 Fiber Optic Cable Cleaver For High Precision Fiber Cutting
Optical Fiber Cleaver Purple Horn-12 Fiber Cable Cutter High Precision
Purple Horn-12 High Precision Cleaver is an instrument for high precision fiber cutting.
Purple Horn-12 can be installed with a variety of holders for ribbon cable up to 12 fibers as well as universal holder which is applicable to 250μm, 900μm, 3.0mm fiber and flat cable.
Work efficiency can be maximized with easy and simple 2 step operations.
The blade provides over 48,000 fiber cleaves by easy and simple blade position selection. Helped by unmatched functionalities, users can achieve the most accurate cleaving and ideally prepare their fusion splicing.
Features
01,Real one-step operation to complete cutting ;
02,Convenient operation,right ot left hand in the hand or desktop;
03,Optical fiber placement is simple ,sutomatically reset after cutting,improve work efficiency;
04,Ingenious presser foot design to prevent fiber damage caused by secondary return;
05,The life of the blade is morethan 3000 times on one side,with 16 cutting end faces;
06,Made of magnesium alloy material, high strength, small submission and light weight;
07,Lining elastic sponge pad .
|
Type |
Single & ribbon fiber cable cleaver |
|
Cladding Diameter |
125μm |
|
Cleaved Length |
Single fiber: 8~20mm / Ribbon fiber: 10mm |
|
Applicable Fiber Cable |
Single fiber: 250μm, 900μm, 3.0mm fiber cable and flat cable |
|
Typical Cleaved Angle |
Less than 0.5 Degrees |
|
Typical Blade Life Span |
Total 48,000 fiber cleaves (1,000 fiber for 1 step * total 16 points * 3 heights) |
|
Operation Steps |
2 Steps |
|
Reclaim Function |
Blade push back |
|
Holder |
Single: Universal holder / Ribbon: Replaceable holder |
|
Dimensions: |
2.44" x 3.93" x 3.14" (62mm x 100mm x 80mm) |
|
Weight: |
0.83lbs (379 grams) |
