Solenoid Valve 23434830 For Ingersoll Rand Air Compressor Valves

Some common solenoid valve does not work,

1  Screw air compressor solenoid valve stuck.Solenoid valve sleeve and spool cooperation gap is very small (less than 0.008m), usually is a single installation, when there are mechanical impurities into or too little lubricating oil, it is easy to get stuck.

Solution: can be used from the head hole into the steel wire, so that it bounced back.The thorough solution is to remove the solenoid valve, remove the spool and spool sleeve, clean with CCI4, so that the spool in the valve sleeve sensitive action.When disassembling, attention should be paid to the installation order and external wiring direction of each component, so as to reinstall and connect correctly, but also to check whether the oil mist nozzle hole is blocked, whether the lubricating oil is satisfied.

2  The solenoid valve of screw compressor leaks air.Air leakage will form a lack of air pressure, which makes the valve difficult to open and close, because of the damage of the sealing gasket or the wear of the slide valve and the formation of several cavity gas channel.

Product Description

• Wide applications, suitable for various kinds of gases and liquids
• State-of Arts design and compact construction
• Reliable service and high sensitivity
• It can work normally even when the working differential pressure is close to zero
