Supply Steel Structure Science School Chemical Laboratory Walk-In Fume Hood
Price:
Negotiable
MOQ:
The minimum order quantity is 1.
Delivery Time:
7-10 days for most products
Brand:
Leiming
Product Description
Supply Steel Structure Science School Chemical Laboratory Walk-In Fume Hood
Product Description
Supply capacity
Supply Ability: 3000 sets of walk-in fume hoods per month
Packing and shipping
Packing details
Inner packaging: foam and pearl cotton between each individual part
Outer packing: standard wooden box or wooden pallet
Packing carton, one piece in a carton
Port
Tianjing, China
Product Properties
| product name | All steel walk-in fume hood |
| Size | 1200/1500/1800x900x2350 or customized size |
| Material | All steel structure |
| All stainless steel structure | |
| Polypropylene PP | |
| Surface treatment | High temperature epoxy powder spraying and baking varnish |
| Liner | Phenolic resin board with a thickness of 5mm, resistant to acid and alkali, equipped with maintenance circuits and gas channels. |
| Lights | The energy-saving lamp is hidden in the ceiling, not in direct contact with the air in the fume hood, easy to replace, explosion-proof lighting, 30W x1 |
| control panel | Multi-function socket, lighting, fan and fan valve control |
| Solid phenolic resin board/epoxy resin board/compact board/ceramic | |
| Work top | Equipped with PP drip cup, one-way faucet and one-way gas |
| Distribution box | 220V / 380V,equipped with leakage and motor protection devices |
| Front window | Composed of 5mm tempered glass window frame, it can move up and down and stop at any position, |
| Process procedure | All steel plates welded by epoxy resin powder have a visual level without welding seams. All water, electricity and gas circuits are safe and convenient, and can be concealed installed in the maintenance hole. |
| Opening height | 0〜800mm |
| Air volume | 1080—1700m 3 / h |
| Power | AC220V—380V / 0.09—4kw |
| Noodle speed | 0.4—0.6m / s noise:<60db |
