SGS 0.9mm 35m/Min Steel Roll Forming Machine For Metal Fence Posts

Price Negotiable
Price: Negotiation
MOQ: 1
Delivery Time: 40work days
Brand: LIMING
Product Description

Roll Forming Machine For Metal Fence Posts



Peach-shaped fences Curved fences are widely used in highways, railways, airports, urban roads, large squares and flowers. It can not only protect the safety of vehicles and pedestrians, but also beautify the space environment. The wooden fence system of the metal column can last for decades, keeping the beauty of the wood outstanding, and at the same time providing the excellent strength of the metal. If you need to produce metal fence posts, we can provide you with a metal fence post roll forming machine

The raw materials of the metal fence post roll forming machine are generally selected, the thickness is 1-1.2mm, cold-rolled or hot-rolled steel, and galvanized steel, which can make the produced fence post products have better corrosion resistance and strength. Ensure the longer service life of the fence post.

The metal fence post roll forming machine is also equipped with a gear box transmission method, which ensures the power of the machine and greatly improves the production efficiency.

The metal fence post roll forming machine also uses a flying saw to cut, so as to ensure that the produced product has a complete cut section and no deformation.

Main Parameters Of Roll Forming Machine For Metal Fence Posts

Description Offered specification
Rolling speed 0-12m/min(not include cutting time)
Rolling thickness 1.2-2mm
Raw material Galvanized steel sheet G550
Effective width 54mm
Roller stations About 16 stations
Roller material Gcr15, coated with chrome, Quenching
Transmission By Chain
Material of chain 45# forged steel with frequency quenching, 12A
Main Motor 7.5kw
