Long Life 12V LiFePO4 Batteries with High Safety and Environmentally Friendly Design for Fast Charging
Features:
High energy density: Compared with traditional lead-acid batteries, it has higher energy density and provides longer use support for equipment.
Long life: The cycle life of this battery can exceed 4000 times, far exceeding lead-acid batteries, reducing the cost of frequent replacement.
High safety: It uses lithium iron phosphate (LiFePO4) material, which has good thermal and chemical stability to prevent safety hazards such as overheating and overcharging.
Lightweight design: Compared with lead-acid batteries of the same capacity, it is smaller in size and lighter in weight, which is easy to transport and install.
Fast charging: It has a faster charging speed, reduces charging time and improves work efficiency.
Intelligent battery management system (BMS): Built-in BMS system monitors the battery status in real time, protects the battery from damage such as overcharging, over-discharging, short circuit, etc., and ensures long-term stable operation.
Environmentally friendly and pollution-free: No heavy metal pollution, more environmentally friendly than traditional lead-acid batteries, and in line with green energy requirements.
Battery Technical Parameters
| Item | Criterion |
| Nominal Voltage | 12.8V |
| Nominal Capacity | 12Ah |
| Battery Type | LiFePO4 Battery |
| Cell Type | 3.2V6Ah |
| Battery Combination | 4S2P |
| Dimension | 151*64*95mm |
| Weight | 1.48kg |
| Charge Cutoff Voltage | 14.6V |
| Discharge Cutoff Voltage | 9.2V |
| Standard Charge and Dischage Current | 6A |
| Max.Charge and Discharge Current | 20A |
| Charging Temperature | 0-55℃ |
| Discharging Temperature | -20-55℃ |
| Storage Temperature | 0-45℃ |
Application
BMS Performance
