High Safety 24V LiFePO4 Batteries with Environmentally Friendly Material and Lightweight Design
Features:
High energy density: Compared with traditional lead-acid batteries, it has higher energy density and provides longer use support for equipment.
Long life: The cycle life of this battery can exceed 4000 times, far exceeding lead-acid batteries, reducing the cost of frequent replacement.
High safety: It uses lithium iron phosphate (LiFePO4) material, which has good thermal and chemical stability to prevent safety hazards such as overheating and overcharging.
Lightweight design: Compared with lead-acid batteries of the same capacity, it is smaller in size and lighter in weight, which is easy to transport and install.
Fast charging: It has a faster charging speed, reduces charging time and improves work efficiency.
BMS: Built-in BMS system monitors the battery status in real time, protects the battery from damage such as overcharging, over-discharging, short circuit, etc., and ensures long-term stable operation.
Environmentally friendly and pollution-free: No heavy metal pollution, more environmentally friendly than traditional lead-acid batteries, and in line with green energy requirements.
Battery Technical Parameters:
| Item | Criterion |
| Nominal Voltage | 25.6V |
| Nominal Capacity | 100Ah |
| Battery Type | LiFePO4 Battery |
| Cell Type | 3.2V100Ah |
| Configuration | 8S1P |
| Dimension | 532*207*215mm |
| Weight | 19.5kg |
| Discharge cut-off voltage |
20V
|
| Charge cut-off voltage | 29.2V |
| Standard charge and discharge current | 50A/Continuing |
| Max. charge and discharge current | 100A/Continuing |
BMS Parameters:
Application:
