Bucket Cylinder Seal Kit 1543279C1 Hydraulic Replacement Service Kit Fits CASE 721C 621C 721B Loader
Price:
Negotiation
MOQ:
Trial order acceptable
Delivery Time:
3-5 days after payment received(public holiday excluded)
Brand:
SUNCAR
Product Description
Bucket Cylinder Seal Kit 1543279C1 Hydraulic Replacement Service Kit Fits CASE 721C 621C 721B Loader
| Product Name | Case Bucket Cylinder Seal Kit |
| Part Number | 1543279C1 |
| Model | CASE 580SK, 721C, 621C, 721B, 621B |
| Material | PU, Rubber, PTFE, NBR, HNBR, ACM, VMQ |
| Place of Origin | China(Mainland) |
| Brand name | SUNCAR |
| Packing | PP bag inside, carton box outside |
| Shipping Mode | By air, by sea, by express(FedEx, UPS, DHL, TNT, etc.) |
| Payment Terms | Western Union, Paypal, T/T, Transfer |
| CertifiC.A.Tion | ISO9001 |
| Warranty | Unavailable |
| Customized | OEM & ODM are welcomed |
| C.A.Tegory Group | Hydraulic cylinder seal kit |
| Condition | New, genuine new |
| Sample | Available |
| Applicable Industries | Building material shops, machinery repair shops, retail, construction work... |
| Feature | High Sealing performance/ wear resistance |
| AppliC.A.Tion | Loader bucket |
Seal ClassifiC.A.Tion:
- According to whether the seal is in contact with its relative moving parts, it can be divided into contact seal and non-contact seal; according to the seal and contact position, it can be divided into circumferential seal and end face seal. End face seal is also called mechanical seal. The centrifugal seal and spiral seal in the dynamic seal are sealed by powering the medium when the machine is running, so they are sometimes called dynamic seals.
- Static seal: There are three main C.A.Tegories: gasket seal, sealant seal and direct contact seal. According to the working pressure, static sealing can be divided into medium and low pressure static sealing and high pressure static sealing. Medium and low pressure static seals usually use softer and wider gasket seals, while high-pressure static seals use harder metal gaskets with a narrow contact width.
- Dynamic seal: It can be divided into two basic types: rotary seal and reciproC.A.Ting seal.
Recommend Products:
Hydraulic Breaker Seal Kit
Regulator Valve Seal Kit
Excavator Hydraulic Parts
Loader Seal Kits
Floating Seal
Blade Lift/Tilt/Steering Cylinder Kit
Control Valve Seal Kit
Swing Motor Seal Kit
Crankshaft Rear Seal
Crankshaft Front Seal
(Main) Control Valve Seal Kit
Track Adjuster Seal Kit
Center Joint Seal Kit
Boom/Arm/Bucket Cylinder Seal Kit
Blade Cylinder Seal Kit
Related Parts:
| Pos. | Part No. | QTY | Parts Name |
| . . | 112551A1 | [2] | JACK BODY |
| 1 | 112015A1 | [1] | TUBE |
| 2 | G100495 | [1] | BUSHING |
| 3 | 1280600C1 | [2] | SEAL |
| . . | NSS | [1] | NOT SOLD SEPARAT |
| 4 | 1978121C2 | [1] | GLAND |
| 5 | D95145 | [1] | WIPER SEAL |
| 6 | G102426 | [1] | BUSHING |
| . . | 1542877C1 | [1] | SEAL KIT |
| 7 | NSS | [1] | NOT SOLD SEPARAT |
| 8 | NSS | [1] | NOT SOLD SEPARAT |
| 9 | 238-5243 | [1] | O-RING |
| 10 | G109300 | [1] | RING |
| 11 | 112019A1 | [1] | PISTON ROD |
| 12 | 1986543C1 | [1] | PISTON |
| 13 | G101994 | [1] | SEAL,RECTANGULAR |
| 14 | G101995 | [1] | SEALING RING |
| 15 | G101996 | [1] | WEAR RING |
| 16 | 28-2052 | [1] | BOLT,Hex |
| 17 | G104989 | [1] | WASHER |
| 18 | 219-1 | [1] | LUBE NIPPLE |
| 19 | 276-2446 | [1] | SELF-TAP SCREW |
| . . | 1543279C1 | [1] | SEAL KIT |
Product Image:
