12V / 24V Electromagnetic Lock Carbon Steel Plated With Blue Zinc
12V / 24V Electromagnetic Lock Carbon Steel Plated With Blue Zinc
Product parameters:
| Model | KR-S6070 |
| Size | 60*70*13.5 mm |
| Name | 24V Electro Magnetic Lock |
| The material of lock body | Q235 cold-rolled sheet |
| The material of lock bolt | Zinc alloy nickel plating |
| Working voltage | DC12V & DC24V |
| Working current | 2.4A/1.2A |
| Maximum power | 28W |
| Response time | Less than 20ms |
| Working temperature | -20℃ ~ +60℃ |
| Working humidity | 5%RH ~ 85%RH |
| Working life | 500,000 times |
| Door weight | 0.5KG~10KG |
| Test | Salt spray testing 24 hours |
| Usage | storage cabinet; express locker; vending machine |
| Certification | CE; FCC; RoHS |
| OEM | Accepted |
Product Main Features:
1. Solenoid driven, support 12V & 24V.
2. QIAOH micro detective switch, 500,000 times operating life.
3. AWG24 wires with PVC protecting tube.
4. Mechanical emergency lever, can be unlocked manually in case of power failure.
5. Zinc Alloy lock tongue, pass more than 24 hours salt spray test.
6. Customizing Logo and lock wires and connectors are available.
Product Details:
Product Applications:
Our products KR-S6070 electromagnetic locker lock can be used in cabinets, delivery locker, vending kiosk locker, storage cabinets, etc.
Feel free to contact us for more information, we sincerely welcome your inquiry.
Hot Tag: 24V Electromagnetic Lock; Cost-effective Cabinet Lock.
