DC14.6V Deep Cycle LiFePO4 Battery 12V 200Ah
Deep Cycle LiFePO4 Battery 12V 200Ah for Solar power system:
This form can't include all we are producing.
| JINWO LiFePO4 Battery/Lithium Battery Pack (12V 5Ah---400Ah) |
||||||||||
|
5/10/20/25/30/40/50/60/80/100/120/150/200/300/400Ah
|
||||||||||
| Item No. | T12005 | T12010 | T12020 | T12025 | T12030 | T12040 | T12050 | T12060 | ||
| Standard Capacity | 5Ah | 10Ah | 20Ah | 25Ah | 30Ah | 40Ah | 50Ah | 60Ah | ||
| Rated Voltage | 12.8V | |||||||||
| Discharge Cut-off Voltage | 10.0V | |||||||||
| Cell Model | IFR32650/32750 | |||||||||
| Casing Material | Steel Case for Single Cells | |||||||||
| Self Discharge Rate | ≤3% after one month | |||||||||
| Life Cycles | 80% left after 2000 times (with 1C constant charge and discharge deep cycle) | |||||||||
| Max Charger Voltage | DC14.6V | |||||||||
| Standard Charge Current | 0.2C | |||||||||
| Protection Function | Short-circuit &Over-current &Overcharge &Over-discharge &Undervoltage Protection | |||||||||
| Product Size(mm) | 151*51*93 | 135*85*85 | 182*76*167 | 184*75*135 | 118*175*175 | 190*165*175 | 190*165*175 | 350*168*179 | ||
| Approx N.W | 0.9Kg | 1.3Kg | 2.8Kg | 3.5Kg | 4.0Kg | 5.5Kg | 7.0Kg | 8.0Kg | ||
| Item No. | OPT12080 | OPT12100 | OPT12120 | OPT12150 | OPT12200 | OPT12200 | OPT12300 | OPT12400 | ||
| Standard Capacity | 80Ah | 100Ah | 120Ah | 150Ah | 200Ah | 200Ah | 300Ah | 400Ah | ||
| Product Size(mm) (changeable) |
260*170*215 | 330*170*220 | 339*173*212 | 502*262*242 | 502*262*242 | 360*220*262 | 502*262*242 | 560*360*200 | ||
| Approx N.W | 11Kg | 16Kg | 19Kg | 24Kg | 35Kg | 38Kg | 45Kg | 65Kg | ||
Application:
1. Electric vehicles:EV/HEV/PHEV, Electric bus, Electric bike, Electric boat, Electric tricycle, Electric quadricycle, Electric scooter, Electric wheelchairs, Golf cart, Marine, Station/SUV /wagon/Caravan, E-tour car, Forklift, etc.
2. Solar and wind energy system:Solar energy storage, PV system, Solar street light, Wind power generation energy storage, etc.
3. Medical devices:Energy power for various kinds of medical devices, etc.
4. Other electric tools and equipments: Lawn mower, Electric saw, UPS, backup storage system, Military equipments, etc.
Advanatge:
1. Specialized in production of lithium iron phosphate batteries for over 4 years.
2. Providing tailor-made high-standard energy solutions in accordance to client's demands.
3. With technical of over 2 years in on-site installation and debugging for more than 1000 HEV and EV.
4. Having made and implemented energy solutions for over 100 styles of EV.
5. With rich experience in drawing up and executing new energy solutions such as special energy-storage systems like wind-solar hybrid power generation and UPS for military and hospital.
6. Whole-journey nanny service after sale.
