200 Amp Hour 4s4p 2.56KWh Electric Boat Motor Battery
12V 200AH Motorhome And Boat Lithium Ion Battery Pack Lifepo4 Rechargeable Battery
| Items | Parameter |
| Battery Type | LiFePO4 |
| Nominal Voltage | 12.8V |
| Nominal Capacity | 200Ah |
| Energy | 2.56KWh |
| Internal Resistance | ≤15mΩ |
| Series & Parallel Application | up to 4 series 4 parallel connected application |
| Limited Charge Voltage | 14.6±0.2V |
| Floating Charge Voltage | 13.8±0.2V |
| Charge Method | CC/CV |
| Discharge Cut-off Voltage | 10.0V |
| Charge Current | 60A |
| Continuous Discharge Current | 100A |
| Pulse Discharge Current (<3s) | 200A |
| Cycle Life | > 6000 cycles |
| Dimension (mm) | Length:525±2 Width:270±2 Height:232±2 |
| Weight | 28Kg |
| Charge Temperature Range | 0~75℃ |
| Discharge Temperature Range | -20~75℃ |
| Recommended Operating Temperature | 15~55℃ |
| Storage Temperature & Humidity Range (Less than 1 month) | -20~35℃, 45~75%RH |
| Storage Temperature & Humidity Range (Less than 3 months) | -10~35℃, 45~75%RH |
| Recommended Storage Temperature & Humidity Range | 15~35℃,45~75%RH |
Lifepo4 battery advantages
1) Long cycle life (2000 cycles) is several times greater than Ni-MH, Ni-Cd or SLA.
2) Non-Toxic, environmentally-friendly product.
3) High safety
LiFePO4 is an intrinsically safer cathode material than Lithium-ion since exothermic reactions can not occur in batteries based on this material
LiFePO4 cells do not incinerate or explode under extreme conditions
4) Good performance in high-current discharge cycles.
Why does Jinwo company have so many successful cases?
1) Has large experience in making and carrying out professional urgent power solution ; ( urgent
2) power for wild units, no power cart in top three hospitals, wind power complementary in India.)
3) Has over 4 years professional technical experience of making lithium iron phosphate battery .
4) Made and carried out power solutions for over hundred EV; ( Including battery combination
technology, structure design and battery management strategy.)
5) Has long term collaboration with Emerson about energy storage, researched and developed
many intelligent battery management system, make sure best performance and lifetime of
battery.
Large-Scales Supply of LiFePo4 battery for Electric Bicycles and Other Light Vehicles.
Using LiFePo4 battery instead of Lead acid battery is inevitable trend.
LiFePO4 Battery Modules Jinwo Supply
| Model | Rated Voltage | Nominal Capacity | Dimension | Weight |
| JW-LFP-1250 |
12.8V
|
50Ah | 195*165*175mm | 7kg |
| JW-LFP-12100 | 100Ah | 328*171*215mm | 12kg | |
| JW-LFP-12120 | 120Ah | 328*171*215mm | 15kg | |
| JW-LFP-12150 | 150Ah | 405*175*240mm | 20kg | |
| JW-LFP-12200 | 200Ah | 520*238*218mm | 22.5kg | |
| JW-LFP-12240 | 240Ah | 495*268*219mm | 27kg | |
| JW-LFP-12250 | 250Ah | 495*268*219mm | 28kg | |
| JW-LFP-12300 | 300Ah | 520*267*218 mm | 33kg | |
| JW-LFP-2450 |
25.6V
|
50Ah | 328*171*215mm | 13kg |
| JW-LFP-24100 | 100Ah | 520*267*218mm | 23kg | |
| JW-LFP-24120 | 120Ah | 520*267*218mm | 30kg | |
| JW-LFP-24150 | 150Ah | 495*160*295mm | 35kg | |
| JW-LFP-24200 | 200Ah | 410*370*200mm | 43kg | |
| JW-LFP-3650 | 38.4V |
50Ah | 483*170*240mm | 22kg |
| JW-LFP-36100 | 100Ah | 520*267*218 mm | 33kg |
