RV Boat 14.6v 1C Charge Lithium Ion Phosphate Battery 12V 100AH With Bluetooth
Lithium Iron Phosphate Solar Energy Storage Battery 12V 250Ah RV Boat Lithium ion Batteries
- Components: lithium iron phosphate battery
- Voltage: 12v
- Weight: 40kg
- Nominal Capacity: 250ah
- Application: electric bike/scooter, electric wheel chair,golf trolley
- cut-off voltage: 10v
- max charge voltage: 14.6v
- standard charge current: 0.2C
- life cycle: more than 2000times, 8-10years
- warranty: 2years,
- color: green, blue,silver,black
- terms of payment: T/T
Application:
1. Electric vehicles: HEV/PEV, Electric bus, Electric bicycle, Electric boat, Electric tricycle, Electric quadricycle, Electric scooter, Electric wheelchairs, Golf cart, Marine, Station/SUV /wagon/Caravan, E-tour car, Forklift, etc.
2. Solar and wind power system:Solar energy storage, PV system, Solar street light, Wind power generation energy storage, etc.
3. Medical devices:Energy power for various kinds of medical devices, etc.
4. Other electric tools and equipments: Lawn mower, Electric saw, UPS, backup storage system, Military equipments, etc.
Specification:
| NO. | Item | General Parameter | |||
| 1 | Cell Model | IFR 32650 | |||
| 2 | Casing Material | Steel Case for Single Cells | |||
| 3 | Standard Capacity | 250Ah | |||
| 4 | Rated Voltage | 12V | |||
| 5 | Max Charge Current | 100A | |||
| 6 | Discharge Cut-off Voltage | 10V | |||
| 7 | Self Discharge Rate | ≤3% one after month | |||
| 8 | Max Continuous Discharge Current | 2.5C5A | |||
| 9 | Standard Charge Current | 0.2C5A | |||
| 10 | Weight(Approx, including case) | About 40kg | |||
| 11 | Impedance(Max, at 1000Hz.) | ≤ 20mΩ | |||
Advantage:
1. High safety: CE, UL approved, safest Li-ion battery so far, with internal protection circuit board(BMS),no fire,no explosion.
2. Green energy:no toxic material contained.
3. Long life cycle: more than 2000 times deep cycle at 1C rate, 6-8 times of lead acid battery
4. No memory effect: highly efficient charge anytime, no reduction of capacity
5. Operation temperature: -20~65°C
6. Smaller size, lighter weight and high capacity: 1/2 size of lead acid battery, 70% size of Ni-MH Ni-Cd battery, 1/2 weight of lead acid battery
7. Good performance at high temperature and high temperature resistance
8. Low self-discharge rate: < 3% monthly
9. High cost performance
----Application:
1. Large-scale electric vehicles: Electric bus, electric car, E-Tour Car
2. Light electric car: E-bike, electric scooter, e-motor, electric golf car, forklift, cleanness car, electric wheelchairs
3. E-tool: Electric drill, electric saw, lawn mower and so on
4. Remote control cars, boat, aircraft, toys
5. Solar and wind power generation energy storage devices
6. Small medical equipment and portable equipment
7. Solar and wind power energy storage system
----Packing and shipping :
The LiFePO4 Battery has passed the UN38.3,
Separate Lithium lron Phosphate Batteries when shipping to prevent short circuits.
All the OptimumNano LiFePO4 Batteries are packed in strong packaging according to the General Packing Requirements of 5.0.2.
Transport Fashion: Be applicable to transport by air, by shipped, by Passenger and Cargo Aircraft.
More information can be obtained from Label with an indication including packed with lithium batteries, handled with care and the special procedures with a telephone number that should be followed when the package is damaged.
