9t7765 Hydraulic Piston Pump Parts Heavy Equipment Maintain Repair
Elephant Fluid Power Made 9T7765 Piston Pump Repair Parts Heavy Equipment Maintain Repair Parts
Elephant Fluid Power can provide 9T7765 Piston, 9T7774 Cylinder block,9T7767 Retainer plate,9T7775 Valve plate,9T7768 Thrust plate and other parts from these series ,equivalent quality as original ,better price,faster lead time,good services.
| Item No. | Name & Description | QTY (pcs) | Remark |
| 1 | DRIVE SHAFT | 1 | SHAFT |
| 2 | PISTON SHOE | 9 | PISTONS |
| 3 | RETAINER PLATE | 1 | SET PLATE |
| 4 | CYLINDER BLOCK | 1 | BARREL |
| 5 | VALVE PLATE(L/R) | 1 | PORT PLATE |
| 6 | SPRING | 1 | COIL SPRING |
| 7 | SWASH PLATE | 1 | YOKE |
| 8 | WASHER | 2 | |
| 9 | RETAINER | 2 | |
| 10 | BOLT | 4 | |
| 11 | SPACER | 2 | |
| 12 | SADDLE BEARING | 2 | |
| 13 | SNAP RING | 1 | |
| 14 | COUNTER PISTON ASSY | 1 | |
| 15 | VALVE ASSY | 1 |
We can provide OEM No.as follows:
| T | |
| 9T2231 | Swash plate |
| 9T8250 | Cylinder block |
| 9T3860 | Retainer plate |
| 9T8249 | Piston shoe |
| 9T8251 | Valve plate LH |
| 9T2232 | Valve plate RH |
| 9T8248 | Rotary group |
| T | |
| 9T7765 | Piston shoe |
| 9T7774 | Cylinder block |
| 9T7767 | Retainer plate |
| 9T7775 | Valve plate LH |
| 9T7768 | Thrust plate |
| 9T7772 Ø126.6 L:134.8 | rings |
| 8J-2022 | Piston |
| 9J-5758 | Valve plate LH |
| 9J-5858 | Valve plate RH |
| 9J-8660 | Cylinder block |
| 9J-7858 | Retainer plate |
| 1U-0406 | Thrust plate |
| 8J6283 | Retainer 1mm |
| 8J6284 | Retainer 127mm |
| 8J5846 | Charge pump |
| 8J7138 | Swash plate |
| 8J6283 | Bearing liner |
| 1B3953 | Bearing liner |
| 8J6322 | Bearing liner |
| 2J8169 | Shaft seal |
| 8J6315 | Small bearing |
| 8J6347 | Spacer |
| 8J7814 | Shaft seal |
| 3G1708 | Seal kits |
equivalent quality,better price,faster lead time ,offering technology supports.We have supplied to some famous brands and series pump parts,
and win a good reputation and welcome for our good quality and honesty,we have exported to 2/3 countries and areas among the world.
We will be your first choice for hydraulic pump parts,we care for our clients,we will develop with them.If you are interested ,pls contact us for more details.
