4GE 2TEL XPON ONU
FTTH Dual Mode XPON ONU Fiber Optical Network Unit 4GE+2TEL WIFI ONU
Description
UT-XP6482 series is designed as HGU(Home Gateway Unit) in deferent FTTH solutions by UT-King, Thecarrier-class FTTH application provides data service access, based on mature and stable, cost-effective XPON technology. It can switchautomatically with EPON and GPON when it access to the EPON OLT or GPON OLT.XPON series adopts high reliability, easy management, configuration flexibility and good quality ofservice (QoS) guarantees to meet the technical performance of the module of China Telecom EPONCTC3,0 and GPON Standard of ITU-TG.984.X.
Features
- Support EPON and GPON, and switch mode automatically
- Support ONU auto-discovery/Link detection/remote upgrade of software
- Plug and play, features auto-detecting, auto configuration, and auto firmware upgrade , etc
- Integrated OAM/OMCI remote configuration and maintenance functi
- Support rich QinQ VLAN functions and IGMP Snooping multicast features
- Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset
- Support 802.11n/ac dual band WiFi
- Support NAT, Firewall function
- Support IPv4 and IPv6 dual stack
- Support SIP protoco
Parameter
| Item |
|
||||||||||||
|
PON Interface
|
|
||||||||||||
| Wavelength | TX: 1310nm, RX: 1490nm | ||||||||||||
| Optical Interface | 1* SC/APC Connector or 1* SC/UPC Connector | ||||||||||||
| POTS interface |
2* FXS, RJ11 connector Support: G.711/G.723/G.726/G.729 codec Support: T.30/T.38/G.711 Fax mode, DTMF Relay Line testing according to GR-909 |
||||||||||||
| LAN Interface | 4*10/100/1000Mbps RJ45 Ports | ||||||||||||
| Wireless |
|
||||||||||||
| Push-Button | 3,For Function of Reset,WLAN,WPS | ||||||||||||
| Operating Condition |
|
||||||||||||
| Storing Condition |
|
||||||||||||
| Power Supply | DC 12V/1.5A | ||||||||||||
| Power Consumption | ≤8 W | ||||||||||||
| Dimension | 155mm×92mm×34mm(L×W×H) | ||||||||||||
| Net Weight | 0.24kg | ||||||||||||
| Ethernet Interface |
4x 10/100/1000BASE-T RJ45 Auto negotiation Auto MDI/MDIX
|
||||||||||||
| XPON | Speed |
Downstream:2.488Gbps Upstream:1.244Gbps |
|||||||||||
| Connector | SC/UPC, pigtail,G.652 Single Mode Fiber | ||||||||||||
| Power level |
Downstream: – Wavelength:1490nm – Sensitivity:-27dBm – Saturation:-9dBm Upstream: – Wavelength:1310nm – TX power:0.5 ~ 5dBm – RMS: 0.5nm |
||||||||||||
| WIFI | Standard |
ThroughPut (11n HT40): ≥140Mbps TX Power (11ac MCS9): 17+2dBm EVM (11AC MCS9) : ＜-32dB ThroughPut (11ac HT80) :≥550Mbps |
|||||||||||
| Antenna |
2.4G antenna :4dBi 5G antenna :4.5dBi |
||||||||||||
| VoIP | Connector | 2 * RJ11 | |||||||||||
| Ringing | 65V RMS ringing voltage | ||||||||||||
| USB | Max 1A for each port | ||||||||||||
