plastic profile Single Screw Extruder Machine 25mx5mx2.3m 20m/min
High Efficiency Single Screw Extruder/Extrusion Line / Machine
Application
Plastic extrusion Machine are mainly produce plastic sheets like PP PS PET PE materials, etc.
Product Description
1,Main technical data
| Item | Unit | Specification | Remark |
| Material | PP,PE,HIPS,PS | ||
| Sheet thickness | mm | 0.3~2.5 | |
| Sheet thickness tolerance | mm | ±0.01 | |
| Screw specification | φ110×33 | ||
| Sheet efficient width | mm | ≤850 | Adjustable |
| Max. extrusion | kg/h | 280 | |
| Speed | m/min | ≤20 | |
| Power | kw | 120 | In fact, about 60% |
| Dimension L×W×H | mm | 13000×2000×2500 | |
2,Composing
| No. | Designation | Unit | Qty. | Remark |
|
1
|
φ110extruder | set | 1 | |
|
2
|
Hydraulic net-change device | set | 1 | |
|
3
|
Die | set | 1 | |
|
4
|
Inclined rolling device | set | 1 | |
|
5
|
Cooling and cutting device | set | 1 | |
|
6
|
Traction device | set | 1 | |
|
7
|
Collection device | set | 1 | |
|
8
|
Controlling cabinet | set | 1 |
Main Features
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in electric parts and operation parts.
3) Running in a high automatization and intellectualization,no pollution
4)The wall panel produced by this kind of extruder has many elements such as environmental protection, heat insulation, moisture-proof, fire protection, sound insulation and fashion. The material is light and easy to install.
main granulator :put the raw material in the main granulator , then it wil be melted into heated solid, there is heating wire, And the wire is made of copper , One of the properties of copper is that conduct heat quickly, Unique cooling structure design, thermal resistance of small, fast heat conduction wire skin, made of high temperature prevention material, which is featured with safe, water proof and high temperature prevention.
