SMC Rapid Mixer Granulator , ODM Maguire Gravimetric Blenders

Gravimetric plastic raw material mixer function features:

1. Max components: 2,4,6,8,12(can be customized)

2. Precision error: 0.1%.-0.3% (Varied from material and component)

3. Weighing sensor brand: HBM, SMC pneumatic elements

4. Resolution of weigh signal is as high as 4,000,000:1

5. Part of material contact is Made of stainless steel, carbon steel frame, surface treatment: plastic spaying, standard color: light gray(customized)

6. Modular design, detachable structure, free-tool maintenance, easy operation

7. 7” true color of touch screen with multi-language choices, dynamic display of mixing process .Centralized screen with 10’’,can start and stop,monitor and input recipe of the 3 blenders.

8. Special designed agitator structure with dual direction to guarantee full blending

9. Interior of hopper is smooth without any blind side. Quick cleaning window and high/low level window

10. Choices of multiple dosing mode, applicable for different applications, accurate proportion is guaranteed.

11. Position of level sensor is mixing chamber is adjustable

12. Imported energy conservation motor

13. Advanced self-adaptation control algorithm, error self-correcting to each single batch, dosing precision can be optimized even under vibration based on unique anti-vibrating structure and algorithm.

14. USB access

15. Throughout statistics function.

16. Grading password control, alarm records and save function for max.100 group of formula saving.

17. Equipped with alertor, records output is available.

18. Remote controlling function. (option)

19.Walthmac application software with self patent

Description of granulator

The pellet machine is a professional equipment for pelletizing and cloth pelleting. Driven by a motor, a V-belt wheel, and a worm gear, under the action of an eccentric crankshaft and a lifting rack, the pentagonal hob on the gear shaft is periodically reciprocated. The material moves continuously and is controlled by the gap between the screen and the rotor to extrude particles. Its production capacity varies with the moisture, type, viscosity and mesh purpose of the material, and it can produce various specifications of particles. When smashing dry materials, the condensed materials are smashed in the drum by the pentagonal hob, and the dry materials are forced to pass through the screen.

The machine has the characteristics of simple and reasonable structure, full energy utilization, advanced granulation method, high efficiency and energy saving. One machine has three functions of granulation, crushing and cloth, which can achieve the purpose of multi-purpose machine. It is suitable for the manufacture of various specifications of particles in the pharmaceutical, chemical, food and other industries. Its great advantage is that the speed of granulation can be adjusted arbitrarily within a certain range, and the uniformity of the cloth can make the wet granules consistent with the dry granules. After the consistent response of users, the machine has uniform granulation, low powder content, convenient operation, long service life, and meets the requirements of GMP specifications.
