120mm Focal Length Line Scan Lenses Hawk Series 172mm Working Distance

Price Negotiable

Price: Negotiable

MOQ: 1 piece

Delivery Time: 7 work days at the soonest

Brand: OPT

Product Description

F5.8-F45 Line Scan Lenses V58 Mount 63mm Image Circle 120mm Focal Length Hawk Series OPT-VHK120/5.8-1.0X

Product Features

◆ Enable high relative illuminance across the entire image and low vignetting
◆ Relative distortion is below 0.01%
◆ It is able to match 63mm image circle and under of line and area scan camera.

◆ High resolution optical design, compatible to line scan camera with 3.5μm pixel

◆ Line scan lenses aperture F/#: F5.8-F45

◆ Distortion(%) of lenses is 0.07% | 0.01% | 0.1%.

◆ Working distance(mm) : 172 | 168.5 | 164.

◆ Object to image distance(mm): 407.3 | 407.2 | 407.3.

◆ Focal length of line scan lenses of hawk series OPT-VHK120/5.8-1.0X is 120mm.

◆ Minimum distortion is 0.01% and total distortion is less than 0.1% and distortion at primary magnification.

◆ Magnification: 0.97X | 1.0X | 1.04X.

◆ Flange focal distance(mm) of OPT-VHK120/5.8-1.0X lens is 172.4 | 175.8 | 180.4.

◆ Weight of OPT-VHK120/5.8-1.0X line scan lens is 0.61kg.

◆ The type of camera mount which is suitable for this line scan len is V58 mount.

Model Explanation

OPT-VHK120/5.8-1.0X

OPT: Brand name

V: V-Mount

HK: Hawk series line scan lenses

120: Focal length 120mm

5.8: F#: 5.8

1.0X: 1.0X primary magnification

Specifications

Product Name	OPT Line Scan Lenses Hawk Series
Model	OPT-VHK120/5.8-1.0X
Focal Length	120mm
Working Distance(mm)	172 \| 168.5 \| 164
Aperture F/#	F5.8-F45
Image Circle(mm)	63mm
Magnification x	0.97X \| 1.0X \| 1.04X
Distortion(%)	0.07% \| 0.01% \| 0.1%
Flange Focal Distance(mm)	172.4 \| 175.8 \| 180.4
Object To Image Distance(mm)	407.3 \| 407.2 \| 407.3
Camera Interface	V58
Weight(Kg)	0.61kg
