F2.8-F32 29MP Fixed Focal Length Lenses Focal Length 25mm 0.71kg 140~∞ WD
Price:
Negotiable
MOQ:
1 piece
Delivery Time:
7 work days at the soonest
Brand:
OPT
Product Description
F2.8-F32 29MP Fixed Focal Length Lenses Focal Length 25mm 0.71kg 140~∞ WD OPT-F2528-29M
Product Features
◆ Line scan lenses aperture F/#: F2.8-F32
◆ Working distance(mm) : 140~∞
◆ High resolution optical design, resolution is up to 90lp/mm
◆ Relative distortion is below 0.9%
◆ Suitable for 36mmX24mm image circle and under of sensor
◆ Relative distortion is below 0.9%
◆ Suitable for 36mmX24mm image circle and under of sensor
◆ Filter thread (mm):M77*P0.75
◆ Focal length of 29MP fixed focal length lenses OPT-F2528-29M is 116mm.
◆ Back focal length (mm):26.4mm
◆ Weight of OPT-F2528-29M 29MP fixed focal length lens is 0.71kg.
◆ Sensor format:44mm | 4/3″ | 1″
◆ FOV angle(H×V×D): 70.29°| 39.60°| 28.72°,55.67°| 30.22°| 21.74°,82.70°| 48.46°| 35.49°
Model Explanation
OPT-F2528-29M
OPT: Brand name
F: F-Mount
25: Focal length: 25mm
28: F#: 2.8
29M: 29M pixel
Specifications
| Product Name | 29MP Fixed Focal Length Lenses |
|---|---|
| Model | OPT-F2528-29M |
| Focal Length | 25mm |
| Aperture range | F2.8-F32 |
| Working Distance(mm) | 140~∞ |
| Filter thread (mm) | M77*P0.75 |
| Distortion(%) | <0.9% |
| Back focal length (mm) | 26.4 |
| Weight(kg) | 0.71kg |
| Sensor format | 44mm | 4/3″ | 1″ |
| FOV angle(H×V×D) |
70.29°| 39.60°| 28.72°
55.67°| 30.22°| 21.74°
82.70°| 48.46°| 35.49°
|
Resolution Comparison
Image taken via 29MP fixed focal length lens Image taken via other lens
Application Examples:
Application Examples:
Surface inspection for beverage can
Dimensions (mm)
| OPT-F2528-29M | |
|
|
